3M 7000031543 3M™ Wire Pulling Lubricant Gel WL-5, Five Gallons, 1 Canisters/Case

3M's WL-5 Wire Pulling Lubricant Gel is compatible with a wide range of cable types and jacket materials, so it is a general-purpose pulling gel rather than one restricted to a single jacket chemistry. Its low coefficient of friction is what protects the jacket in practice: less drag through the conduit means less chance of abrading or tearing the sheath on a long or multi-bend pull.

WL-5 pulling gel is rated for use from 20 to 110 degrees F (-6.7 to 43 degrees C). Below 20 F it is outside its stated range, so for a winter pull in unheated space keep the pail warm and stage it indoors until you need it. On the hot end, 110 F covers most attic and rooftop conduit work.

WL-5 is a low residue gel, which matters on any raceway you expect to re-pull or add to. Less dried film on the conduit wall and the cable jacket means the next crew pulling into that run is not fighting hardened lubricant. If you are wiring a data or tenant-improvement space where circuits get changed out, that is the reason to pick a low residue gel over a heavy wax.

A gel like 3M WL-5 clings to the cable and the conduit mouth instead of running off, so it stays where you apply it on vertical risers and long horizontal runs, and it is easy to hand-apply or pour into the conduit entry. Liquids spread faster and are easier to pump but drain toward the low point; waxes carry more body but tend to leave more film behind. WL-5 splits that difference: gel consistency with low residue.

WL-5 is RoHS 2011/65/EU compliant without exemption, so it clears the restricted-substances line on most public-sector and institutional submittals outright rather than relying on an exemption that has to be justified. It is also manufactured in the United States, which covers the domestic-origin question that comes up on federal and many state-funded jobs.

The gel is translucent white. Because it is not pigmented, drips at the conduit entry or on a device box are far less conspicuous than a colored lubricant would be, which is worth knowing on finished-space work where you are pulling into an existing wall. Wipe it off before it dries and the low residue formula comes away easily.

Order 3M part number 7000031543 for WL-5 Wire Pulling Lubricant Gel in the five gallon canister. That is the size to buy when you are pulling feeders or large conduit runs on a sustained job; a quart or gallon is the right call for service and small branch work.
