HAGER 1303 Full Surface, Double Acting, Spring Hinge, Grade 1   Certifications: ANSI K81041; Finishes: USP, US3, US4, US26D; Door Thickness: 1-1/4" x 2" Features: Adjustable. 3 hinges required per door. Non-handed.; Fasteners: 6" - #10 x 1-1/4"...

HAGER 212 DOOR STOP SPECIFICATIONS Finishes: US3, US4, US5, US9, US10, US15, US15A, US19, US26, US26D Material: Zinc Alloy; Notes: For use with residential hinges; For use where standard door stops are not desirable; For use with narrow...

HAGER 270D Kick Down Door Holder Certifications: Meets ANSI A156.16 for L01381 Fasteners: Three #6 x 3/4'' OPHWS; Arm: 3-1/2" (89 mm); Material: Cast brass with rubber tip; Notes: Provides simple hold and release with a touch of the foot; 2-1/4" (57...

HAGER 1173 HALF SURFACE HINGE   Applications: For use on regular weight hollow metal or wood composite doors with hollow metal frames requiring low frequency service.. Certifications: ANSI A8433; Finishes: USP, US10, US10A, US10B, US26D; Fastener...

HAGER BB1168 FULL MORTISE FIVE KNUCKLE HINGE   Applications: For use on heavy weight doors and doors requiring high frequency service. Certifications: ANSI A8111; Finishes: LS, USP, US3, US4, US10, US10A, US10B, US26, US26D; Features: Four ball...

HAGER 241F DOME SPECIFICATIONS Finishes: US3, US4, US5, US9, US10, US15, US15A, US19, US26, US26D Fasteners: One #14 x 1-1/2" FPHWS, one 1/4-20 x 3/4" FPHMS, one 1/4-20" lead anchor, and one plastic anchor; Code Compliance: Meets ANSI A156.16 for L02142...

HAGER 550 SINGLE ACTING HW RACK AND PINION PIVOT   Finishes: US26D; Door Thickness: 1-3/4" (44 mm); Fastener Size - Machine: upon request; Fastener Size - Wood: 1-1/4 x 12 F.H.; Maximum Door Length: 3' (914 mm); Maximum Door Weight: 150 lbs...

HAGER 512 CAMTROL DOUBLE ACTING HEAD AND FLOOR PIVOT   Applications: Surface Application in Masonry Floors - Head and Floor Pivots with Door Release (Set); Finishes: US26D; Fastener Size - Wood: Door Mount Brackets; 1-1/4 x 12 FH Head Cam...

HAGER 780-111 - CONCEALED LEAF CONTONOUS HINGES   Applications: Lead lined model for hospital x-ray room doors with double row of fasteners to straddle lead (specify "LL"). Frame and door leaf alignment ribs for proper hinge and door...

HAGER 780-157 - FULL SURFACE CONTONOUS HINGES   Applications: For or surface applications where frame face dimension is limited. Security moldings. 1/16" (1.5 mm) inset. Clearance: 1/32" (1 mm) minimum recommended for hinge side. Plus standard...

HAGER 1756 - 185 Degree One Way Door Viewer Certifications: Meets ANSI A156.16 for L03223 Finishes: US3, US4, US5, US10A, US15, US15A, US19, US26, US26D; Door Thickness: 1-3/8" - 2-1/8" (35 mm - 54 mm) Fire Rating: UL10B 90 minute; Material:...

HAGER 253 REINFORCING FULL SURFACE PIVOT   Finishes: US2C; Door Thickness: 1-3/4"; Fastener Size - Machine: 3/4" x 1/4-20"; Fastener Size - Wood: 1-1/4" x 14"; Notes: Projections from centerline of pivot to face of door; Projection:...

HAGER 5100 SERIES CLOSER 5100 Series Closers are heavy duty door closers constructed of cast iron to be installed on exterior and interior doors that are subject to high use and potential abuse. They are designed and engineered for reliability and...

HAGER 1150 FULL MORTISE SPRING HINGE   Certifications: ANSI K51071F; Finishes: US32, US32D; Knuckles: 3; Fastener Size - Machine: 12-24 x 1/2"; Fastener Size - Wood: 12 x 1-1/4"; Nots: Strong wind conditions, drafts, carpeting drag,...

HAGER 1191 FULL MORTISE FIVE KNUCKLE HINGE   Finishes: US3, US4, US5, US9, US10, US15, US15A, US19, US26, US26D; Fastener Size - Machine: #12-24 x 1/2"; Fastener Size - Wood: #12 x 1-1/4" Features: Non-rising removable pin with button tip and...

HAGER 1150 FULL MORTISE SPRING HINGE   Certifications: ANSI K81071F; Finishes: USP, US3, US4, US10, US10A, US10B, US26D; Knuckles: 3; Notes: Hager does not recommend using spring hinges on doors over 7'0".; For maximum versatility use all spring...

HAGER 1251 FULL MORTISE SPRING HINGE   Certifications: ANSI K81071F; Finishes: USP, US3, US4, US10, US10A, US10B, US26D; Fastener Size - Machine: 12-24 x 1/2"; Fastener Size - Wood: 12 x 1-1/4"; Knuckles: 3; Notes: Hager does not recommend using...

HAGER 1252 FULL MORTISE SPRING HINGE   Certifications: ANSI K81071F; Finishes: USP, US3, US4, US10, US10A, US10B, US26D; Fastener Size - Machine: 12-24 x 1/2"; Fastener Size - Wood: 12 x 1-1/4"; Knuckles: 3; Notes: Hager does not recommend using...

HAGER 1279 FULL MORTISE SPRING HINGE   Applications: For use with medium frequency doors or doors requiring low frequency service. Certifications: ANSI A8133; Finishes: USP, US3, US4, US10, US10A, US10B, US26D; Knuckles: 5; Features: Non-rising...

HAGER 133S PUSH BARS   Finishes: US32D; Fasteners: 1/4" - 20 x 2- 1/4" FPHMS with finish washers. May be ordered with Type 5 concealed mountings at extra charge Base Diameter: 3/4" (19 mm) Round Material: Stainless Steel Projection: 2-1/4" (57...

HAGER 1414 FLOOR STOP   Fasteners: Four #6 x 3/4" FPHWS; Bolt Diameter: 1/2" (13 mm) Bolt Throw: 15/16" (24 mm) Faceplate: 3/4" x 6" (19 mm x 181 mm) Material: Brass faceplate with steel components Notes: Backset: 7/16" (11 mm) Strike Size: 7/8" x...

HAGER 15S Light Duty Flush Cup Pull Finishes: US3, US4, US10, US10B, DBZ, US26, US26D, US28, US32D Certifications: Meets ANSI A156.6 for J403 Pulls; Fasteners: two (2) #6 x 5/8" FPHWS Cup Clearance: 3/4" (19 mm). Material: Aluminum, Brass, Bronze,...

HAGER 1716 ACORN DECORATOR TIP   Finishes: US3, US15; Material: Brass with Stainless Steel Pin; Notes: Hinge size - 3-1/2" (89 mm), 4" (102 mm), 4-1/2" (114 mm), 5" (127 mm), 6" (152); Conversion tips and pins for architectural grade hinges...

HAGER 1848 FULL MORTISE RESIDENTIAL HINGE   Notes: Hager residential hinges are provided without lubrication. We recommend lubricating the hinges after installation. All residential hinges conform to the "Light Weight" requirements of ANSI A156...
