OVERVIEW
The Alarm Lock DL2700LD Trilogy® T2 Digital Lock with LocDown™ was designed specifically for classroom/campus safety. Remove access and lockdown indicator make it a valuable security device in the event of a campus emergency when lockdown response time is critical. In the same family as the DL2700 Series standalone pushbutton cylindrical lock.
Key benefits and benefits of the Trilogy® T2 Digital Lock with LocDown™
- Remote control keyfob activation (up to 100 feet away and up to 4 locks)
- Durable petal pushbutton panel (up to 100 access codes)
- Stand-alone power - 5 AA batteries for reliability and operability during building power outages
- Bright lockdown indicator bar for high visibility inside the room
- Grade 1 durability
- 100% programmable and easy installation (in less than 1 hour)
- Ideal for school and campuses security
Operation
Clutch mechanism permits turning lever without retracting latch and reduces stress on lock bodies and spindle. Outside lever free turning in locked position. Entering access code, key bypass, or remote bypass will allow lever to retract latch. Inside lever always instant egress.
Technical Data
- Backset: 2-3/4".
- Door Thickness: 1-5/8" to 1-7/8"
- Latchbolt: UL Listed, fire rated, 3 hours, 1/2” throw, solid brass, deadlocking. Reversible. Adjustable front for flat or beveled doors.
- Strike: 1-1/8” x 2-3/4” T strike & 1-1/4” x 4-7/8” ASA strike included. With screws for wood or metal jambs.
- Latch Front: 1-1/8” x 2-1/4” wrought brass or stainless steel.
- Power: 5 AA alkaline batteries are now rated at 200,000 cycles, supplied. Audible low battery alert, visual and audible entry indicators, unique Flex Drive® motor
- Door Prep: Standard ANSI 161 Series Prep, modified by adding additional through-bolt holes.
- Compliances: Grade 1, heavy duty cylindrical lockset, UL listed and FCC certified. ADA compliant leversets.
FEATURES
- Grade 1 Durability - BHMA Grade 1 lockset with rugged clutch plus vandal-proof all metal keypad.
- 100% fingertip programmable - easy installation in less than an hour.
- Supports standard and IC core prep cylinders.
- Up to 100 codes + 3 service codes + 1 master.
- Multi-level user capability: Master, manager, user, service codes.
- Individual, group or total user lockout codes.
- All 2700LD models are Weatherproof and good for exterior use -31˚ to 151˚F (-35 to 66˚C).
- Long-life battery operated.
DOWNLOADS & RESOURCES
Manufacturer Resources
Product Specs
- Category:
- Mechanical Locks
- Series:
- DL2700 Series
- Grade:
- Grade 1
- Standard Cylinder:
- Conventional Cylinder
- Power:
- Battery Operated
- Product Type:
- Cylindrical Locks
- Warranty:
- 2 Year Limited
- Application:
- Pushbutton Keypad & remote lockdown activation
- Door Thickness:
- 1-5/8" to 1-7/8"
- Backset:
- 2-3/4"
- Handing:
- Non-Handed
- Lock Type:
- Cylindrical
- Model:
- DL2700LD
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Bored Locksets
- Subcategory:
- Cylindrical Locks
- Reader Type:
- Keypad
- Strike:
- T-Standard and ASA
- Commercial/Residential:
- Commercial
- Batteries:
- AA (5)
- Battery Operated:
- Yes
- Audit Trail:
- No
- User Codes:
- 100
- Weather Proof:
- Yes
