Alarm Lock Trilogy Touch T2 Cylindrical Lock with EZ-Touch Backlit Keypad - 100 User Codes

Alarm Lock Trilogy Touch T2 Cylindrical Lock with EZ-Touch Backlit Keypad - 100 User Codes

Advanced Touch-Sensitive Electronic Lock with Grade 1 Durability

The Alarm Lock Trilogy Touch T2 Cylindrical Lock delivers professional-grade access control with an innovative EZ-Touch backlit keypad that illuminates on contact. This Grade 1 electronic lock accommodates doors from 1-5/8" to 1-7/8" thick with standard 2-3/4" backset and operates on 5 AA batteries rated for 200,000 cycles. The weatherproof design functions reliably from -31°F to +151°F, making it suitable for both interior and exterior commercial applications.

Professional Features & Benefits

• Door Compatibility: Designed for 1-5/8" to 1-7/8" door thickness with 2-3/4" standard backset for versatile installation options.
• Extended Battery Life: 5 AA alkaline batteries rated at 200,000 cycles provide class-leading longevity and lowest total cost of ownership.
• Multi-Level Access Control: Supports up to 100 different user codes (3-6 digits) including 1 master, managers, 90 basic users, and 3 one-time service codes.
• Grade 1 Construction: Heavy-duty cylindrical lockset with rugged clutch mechanism and UL listed fire-rated latchbolt for commercial durability.
• Weatherproof Operation: All Trilogy models now weatherproof as standard with operating range from -31°F to +151°F (-35°C to +66°C).
• Touch-Sensitive Interface: Sleek EZ-Touch sense panel with illuminating numbers that brighten to touch and go dark after use with easy clean-plane surface.
• Flexible Programming: 100% touchscreen keypad programmable at the lock with fingertip control for individual, group, or total user lockout codes.
• Enhanced Security Features: 2-wire remote override capability, visual and audible entry indicators, and allowable entry time from 5 to 20 seconds.

Technical Specifications

• Application: Pushbutton Keypad
• Audit Trail: No
• Backset (Distance): 2-3/4"
• Battery Operated: Yes
• Commercial/Residential: Commercial
• Door Strike: T-Standard and ASA
• Door Thickness Range: 1-5/8" to 1-7/8"
• Electronic: Yes
• Lock Type: Cylindrical
• Power: Battery Operated
• Product Attribute: Electronic Locks
• Product Category: Electronic Locks
• Product Group: Mechanical Locks
• Product Model: TL2700
• Product Subgroup: Bored Locksets
• Product Type: Cylindrical Locks
• Reader Type: Keypad
• Series: TL2700 Series
• Standard Cylinder: Conventional Cylinder
• Subcategory: Cylindrical Locks
• User Codes: 100

Installation & Operation

1. Verify electrical requirements are met with 5 AA alkaline batteries. Confirm door thickness is within 1-5/8" to 1-7/8" range before proceeding.
2. Disconnect any existing power sources and remove old hardware following safety procedures.
3. Prepare door using standard ANSI 161 series prep, modified by adding additional through-bolt holes as specified in manufacturer templates.
4. Install the lock mechanism and secure all mounting hardware per manufacturer torque specifications.
5. Configure user codes and operational settings including entry time (5-20 seconds), keypad tones, passage mode, and any lockout functions per application requirements.
6. Install batteries and test all functions including normal operation, remote override capability, visual and audible indicators, and low battery alert system.
7. Complete final inspection and document all programmed codes and settings. Refer to manufacturer documentation for complete programming instructions and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Weatherproof Construction

All Trilogy models now feature weatherproof construction as standard, operating reliably in temperatures from -31°F to +151°F (-35°C to +66°C). This enhanced environmental protection makes the lock suitable for exterior doors and harsh indoor environments while maintaining consistent performance and extended battery life.

Why Choose Alarm Lock Quality?

Alarm Lock Trilogy Touch T2 locks deliver professional-grade reliability with Grade 1 heavy-duty construction and rugged clutch mechanism rated for 200,000 battery cycles. UL listed and FCC certified with fire-rated latchbolt construction, these locks provide class-leading battery life and lowest maintenance requirements. Engineered for demanding commercial applications where dependable electronic access control and weatherproof performance are essential.
