Detex EAX-4200SK Exit/Door Prop Alarm Kit with 24VAC Transformer and Rim Cylinder

Detex EAX-4200SK Exit/Door Prop Alarm Kit with 24VAC Transformer and Rim Cylinder

Complete Door Management Alarm Solution

The Detex EAX-4200SK Exit/Door Prop Alarm Kit provides comprehensive door monitoring with door prop/door held, intrusion/door forced, and exit alarm detection capabilities in one master unit. This complete kit includes back box, surface magnetic switch contacts, 24VAC transformer, and rim cylinder for immediate installation. The unit mounts in a 3 gang box and offers field selectable alarm timing and delay options for customized security applications.

Professional Features & Benefits

• Complete Kit Configuration: Includes back box, surface magnetic switch contacts, 24VAC transformer, and rim cylinder for comprehensive door monitoring installation.
• Triple Detection Capability: Monitors door prop/door held, intrusion/door forced, and exit alarm conditions for complete access control point security.
• Field Selectable Options: Configurable alarm timing and alarm delay options allow customization for specific application requirements.
• Audible Warning System: Built-in audible warning reduces false door held alarms and provides immediate local notification.
• Remote Monitoring Integration: Alarm status relay enables remote annunciation and integration with building security systems.
• Automatic Reset Function: Automatic alarm reset/rearm upon door closure eliminates manual intervention for normal operation cycles.
• Professional Installation: Mounts in standard 3 gang box with reset/bypass keyswitch and remote input for flexible control options.
• Visual Status Indication: Integrated visual status indicator provides immediate system status confirmation for security personnel.

Technical Specifications

• Commercial/Residential: Commercial
• Product Category: Exit Devices and Trim
• Product Group: Exit Devices and Trim
• Product Model: EAX-4200SK
• Product Subgroup: Exit Control Locks and Alarms
• Product Type: Exit/Door Prop Alarms
• Series: EAX-4200SK
• Subcategory: Exit/Door Prop Alarm

Installation & Operation

1. Verify electrical requirements match available power supply. Confirm 24VAC power capacity before proceeding with installation.
2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
3. Mount the unit in the specified 3 gang box location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
5. Configure operational settings including field selectable alarm timing and delay options per application requirements.
6. Restore power and test all functions including door prop detection, intrusion monitoring, exit alarm operation, and integration with connected systems.
7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

• Commercial Building Security Systems
• Retail Loss Prevention
• Healthcare Facility Access Control
• Educational Institution Safety Systems
• Industrial Facility Monitoring
• Emergency Exit Compliance
• Government and Municipal Buildings

Why Choose Detex Quality?

Detex EAX-4200SK Door Management Alarm systems deliver professional-grade reliability with comprehensive monitoring capabilities and field selectable configuration options. The complete kit design with included transformer and rim cylinder ensures immediate installation readiness. Engineered for demanding commercial applications where dependable door monitoring and access control performance is essential.
