Eaton Meter Stack Commercial 3...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$3,473.94
$3,123.81
Eaton 35MM ercial meter stack, Plugin socket, 200A, Al, Bus:1200A, Lever, Depends on selected MCB, 3R, 5-jaw, Sockets:3, 3- in, 1- out, A-B, EHD2_, CCV2_X, CCVH2_X, CVS2_XMM, CV2_XMM,CVH2_XMM, Ringless, Socket:225A, 120/240Vac

Eaton Meter Stack Commercial 35MM 200A 3-Socket 3-Phase Input Single-Phase Output NEMA 3R

(No reviews yet) Write a Review

Model: 35MM320R12

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,473.94
$3,123.81
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton 35MM140HR1240 35MM commercial meter stack, Plugin socket, 400A, Al, Bus:1200A, Lever, 3R, Depends on selected main circuit breaker, 5-jaw, Sockets:1, Three-phase in, single-phase out, A-B, 400A, K-frame included, Ringless, Socket: 400A, 120/240

Eaton 35MM140HR1240 35MM commercial meter stack, Plugin socket, 400A, Al, Bus:1200A, Lever, 3R, Depends on selected main circuit breaker, 5-jaw, Sockets:1, Three-phase in, single-phase out, A-B, 400A, K-frame included, Ringless, Socket: 400A, 120/240

Model: EAT-35MM140HR1240

Eaton 35MM commercial meter stack, Plugin socket, 400A, Al, Bus:1200A, Lever, 3R, Depends on selected main circuit breaker, 5-jaw, Sockets:1, Three-phase in, single-phase out, A-B, 400A, K-frame...

Eaton

$17,996.59
$17,946.59

Eaton 35MM Commercial Meter Stack

Professional Multi-Tenant Electrical Metering Solution

The Eaton 35MM Commercial Meter Stack delivers exceptional electrical power distribution and metering performance for multi-tenant commercial applications. This 200A meter stack with 1200A bus capacity provides reliable electrical distribution designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Multi-Tenant Metering Performance

  • 200A Socket Capacity with 1200A Bus Rating - High-capacity electrical distribution for multiple tenant connections with robust bus system for reliable power delivery
  • 3-Socket Configuration - Accommodates three separate meter connections for individual tenant billing and electrical monitoring
  • 3-Phase Input to Single-Phase Output - Flexible power distribution converting three-phase utility supply to single-phase tenant services
  • 5-Jaw Socket Design - Professional meter socket configuration ensuring secure utility meter installation and reliable electrical connections

Weather Protection & Installation

  • NEMA 3R Enclosure Rating - Weather-resistant outdoor installation protection against rain, sleet, and snow for reliable operation
  • Aluminum Construction - Lightweight yet durable material providing excellent corrosion resistance and long-term electrical performance
  • Plug-In Socket Design - Simplified meter installation and maintenance with secure plug-in connections for utility meters

Technical Specifications

Socket Rating: 200A, Bus Rating: 1200A, Number of Sockets: 3, Socket Configuration: 5-Jaw, Phase Configuration: 3-Phase Input/Single-Phase Output, Voltage: 120/240V AC, NEMA Rating: 3R, Construction Material: Aluminum, Socket Type: Plug-In, Dimensions: 52.63" H x 18.25" D x 8.75" W, Weight: 147 lbs, Certifications: UL Listed, Utility Approvals: Indiana Michigan Power (IMP) (AEP East)

Installation & Usage

  1. Verify utility requirements and obtain necessary permits for meter stack installation
  2. Mount meter stack securely to appropriate foundation or wall structure following local electrical codes
  3. Connect incoming 3-phase utility service to main bus terminals with proper torque specifications
  4. Install individual tenant service conductors to each socket output terminals
  5. Coordinate with utility company for meter installation in each 5-jaw socket
  6. Perform electrical testing and inspection to verify proper installation and safety compliance

Professional Applications

Ideal for:

  • Multi-Tenant Commercial Buildings - Office complexes, retail centers, and mixed-use developments requiring individual tenant metering
  • Apartment and Condominium Complexes - Residential multi-unit buildings with separate electrical service metering requirements
  • Strip Mall and Shopping Centers - Commercial retail spaces with multiple tenant electrical services and individual billing needs
  • Industrial Multi-Tenant Facilities - Warehouse and light industrial complexes with separate tenant electrical monitoring
  • Mixed-Use Developments - Combined residential and commercial projects requiring flexible metering solutions
  • Utility Service Upgrades - Electrical service modernization projects requiring new metering infrastructure
  • Property Management Applications - Facilities requiring individual tenant electrical usage monitoring and billing
  • Commercial Electrical Distribution - Professional electrical systems requiring reliable multi-point metering capabilities

Commercial Metering Advantage

The 35MM series meter stack design provides professional-grade electrical distribution with utility-approved metering capabilities, featuring robust 1200A bus capacity for reliable power distribution to multiple tenant services while maintaining individual metering requirements for accurate billing and electrical monitoring.

Why Choose Eaton Quality?

Eaton's century-plus experience in electrical power management innovation ensures reliable commercial metering solutions with UL Listed safety compliance and utility approvals. Trusted by electricians, electrical contractors, and facility professionals worldwide for dependable multi-tenant electrical distribution systems that deliver consistent performance and professional reliability in demanding commercial applications.

Manufacturer Resources

Product Specs

Certifications:
UL Listed
Product Height:
52.63 in
Product Length Depth:
18.25 in
Product Type:
Meter Stack
Product Weight:
147 lb
Product Width:
8.75 in
Utility Approvals:
IN : Indiana Michigan Power (IMP) (AEP East)
Product Subgroup:
Meter Stack
Product Group:
Electrical
Department:
Electrical
