Eaton BR Thermal Magnetic Circuit Breaker 15A Single-Pole 120V with CTL Plug-On Design

Eaton BR Thermal Magnetic Circuit Breaker 15A Single-Pole 120V with CTL Plug-On Design

Professional Circuit Protection with CTL Plug-On Technology

The Eaton BR thermal magnetic circuit breaker delivers reliable single-pole circuit protection at 15A rating for 120V applications. This Type BD circuit breaker features CTL plug-on mounting for Type BR loadcenters, includes rejection tab feature for enhanced safety, and accommodates #14-4 AWG Cu/Al wire connections with 10 kAIC interrupt rating for dependable electrical protection.

Professional Features & Benefits

• 15A Single-Pole Rating: Provides precise overcurrent protection for 120V branch circuits with reliable thermal magnetic trip mechanism.
• 10 kAIC Interrupt Rating: Delivers robust fault current interruption capability for enhanced electrical system safety and protection.
• CTL Plug-On Design: Enables quick, secure installation in Type BR loadcenters with positive connection and easy serviceability.
• Rejection Tab Feature: Prevents improper installation and ensures compatibility only with appropriate loadcenter configurations.
• #14-4 AWG Cu/Al Compatibility: Accommodates both copper and aluminum conductors across a wide wire size range for versatile wiring applications.
• UL 489 Listed: Meets rigorous safety and performance standards for molded case circuit breakers and circuit breaker enclosures.
• Switch Duty Rated: All 15 and 20 ampere single poles are switch duty rated for enhanced operational flexibility.

Technical Specifications

• Amperage Rating: (2) 15A
• Catalog Notes: All Type BD Duplex and BQ Quadplex circuit breakers carry listing for HACR applications. All 15 and 20 ampere single poles are switch duty rated.
• Certifications: UL 489
• Circuit Breaker Type: BR
• Compliances: Federal Specifications Classification W-C375
• Department: Electrical
• Interrupt Rating: 10 kAIC
• Main Circuit Breaker: BD
• Mounting Method: Plug-on
• Number Of Poles: Single-pole
• Product Group: Electrical
• Product Height: 2.5 in
• Product Length Depth: 2.9 in
• Product Subgroup: Circuit Breaker
• Product Type: Thermal Magnetic Circuit Breaker
• Product Weight: .35 lb
• Product Width: 1 in
• Special Features: Includes rejection tab feature
• Used With: Type BR Loadcenters
• Voltage Rating: 120 V
• Wire Size: #14-4 AWG Cu/Al
