Eaton Thermal Magnetic Circuit Breaker Four-Pole 30A 120/240V 10kAIC BR Type Quad Common Trip

Eaton BR Thermal Magnetic Circuit Breaker Four-Pole 30A

Professional Quad Circuit Breaker for Type BR Loadcenters

The Eaton BR Thermal Magnetic Circuit Breaker delivers exceptional electrical protection performance for residential and commercial electrical distribution systems. This four-pole 30A circuit breaker provides reliable thermal-magnetic protection with 10 kAIC interrupt rating designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Advanced Electrical Protection

• Four-Pole 30A Configuration - Provides comprehensive protection for multi-wire branch circuits with (4) 30A capacity for balanced electrical loads
• 10 kAIC Interrupt Rating - Delivers reliable short-circuit protection with 10,000 ampere interrupting capacity for residential and light commercial applications
• 120/240V Voltage Rating - Compatible with standard residential and commercial electrical systems for versatile installation applications
• Common Trip Design - Ensures simultaneous tripping of all poles for enhanced electrical safety and code compliance

Professional Installation Features

• Type BR Loadcenter Compatibility - Designed specifically for Eaton Type BR loadcenters ensuring proper fit and electrical performance
• Quad 1-Inch Design - Space-efficient quad configuration maximizes circuit capacity in standard electrical panels
• Wire Size Compatibility - Accepts #14-4 AWG Cu/Al conductors for flexible wiring applications and professional installation

Technical Specifications

Amperage Rating: (4) 30A, Voltage Rating: 120/240V, Number of Poles: Four-pole, Interrupt Rating: 10 kAIC, Circuit Breaker Type: BR, Trip Type: Common breaker trip, Wire Size: #14-4 AWG Cu/Al, Used With: Type BR Loadcenters, Certifications: UL 489, Compliances: Federal Specifications Classification W-C375, Dimensions: 3" H x 2" W x 3" D, Weight: 0.8 lb, Catalog Notes: Non-CTL

Installation & Usage

1. Verify electrical panel compatibility with Type BR loadcenters and confirm proper amperage requirements
2. Turn off main electrical power and verify de-energized state using appropriate electrical testing equipment
3. Install quad circuit breaker into designated panel slots ensuring proper alignment and secure mounting
4. Connect branch circuit conductors to breaker terminals using proper torque specifications for #14-4 AWG Cu/Al wire
5. Verify common trip operation and proper electrical connections before energizing the circuit
6. Test circuit breaker operation and document installation per electrical code requirements

Professional Applications

Ideal for:

• Residential Electrical Systems - Multi-wire branch circuits, kitchen appliance circuits, and HVAC equipment protection
• Commercial Electrical Distribution - Office building electrical panels, retail electrical systems, and light commercial applications
• Multi-Wire Branch Circuits - Balanced electrical loads requiring simultaneous protection across multiple conductors
• Appliance Circuit Protection - Electric ranges, dryers, and other 240V appliances requiring four-pole protection
• HVAC System Protection - Air conditioning units, heat pumps, and electrical heating systems
• Electrical Panel Upgrades - Modernizing electrical distribution systems with reliable thermal-magnetic protection
• Code Compliance Applications - Meeting NEC requirements for multi-wire branch circuit protection
• Professional Electrical Installations - New construction and electrical renovation projects requiring quad circuit protection

Thermal-Magnetic Protection Advantage

Eaton's proven thermal-magnetic technology combines thermal overload protection with magnetic short-circuit protection, providing reliable electrical safety for both sustained overloads and instantaneous fault conditions. The common trip design ensures all poles operate simultaneously, meeting electrical code requirements for multi-wire branch circuits while providing enhanced electrical safety.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton delivers the reliability and performance that electrical professionals trust. UL 489 listed and compliant with Federal Specifications, this BR series circuit breaker represents Eaton's commitment to electrical safety, quality construction, and dependable performance for electricians, electrical contractors, and facility professionals worldwide.
