Eaton Main Breaker Kit 100A Pow-R-Xpress PDD2XF Single Three Phase Top Bottom Mount

Eaton Pow-R-Xpress Main Breaker Kit

Professional Electrical Power Distribution Equipment

The Eaton Pow-R-Xpress Main Breaker Kit delivers exceptional electrical power management and control performance for commercial and industrial power distribution applications. This 100A main breaker kit provides reliable electrical protection designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Electrical Performance Excellence

• 100A Amperage Rating - Provides robust current capacity for demanding commercial and industrial electrical distribution systems with reliable overcurrent protection
• Single and Three-Phase Compatibility - Versatile phase configuration supports both single-phase and three-phase electrical systems for maximum installation flexibility
• PDD2XF Circuit Breaker Type - Advanced circuit breaker technology ensures dependable electrical protection and system reliability for critical power distribution applications
• Pow-R-stock Series Design - Engineered with Eaton's proven electrical protection technology for consistent performance in professional electrical installations

Installation & Protection Features

• Top and Bottom Mounting Configuration - Flexible mounting options accommodate various electrical panel configurations and installation requirements for professional electrical systems
• Compact Design Dimensions - Space-efficient 6" x 4" x 3" footprint optimizes electrical panel space utilization while maintaining full electrical protection capabilities
• UL 67 Certification - Meets rigorous electrical safety standards ensuring compliance with professional electrical codes and installation requirements

Technical Specifications

Amperage Rating: 100A, Phase Configuration: Single-phase and three-phase compatible, Circuit Breaker Type: PDD2XF, Series: Pow-R-stock, Mounting: Top and bottom mounting, Dimensions: 6 in L x 4 in W x 3 in H, Weight: 5 lb, Certifications: UL 67 Listed

Installation & Usage

1. Verify electrical system compatibility with 100A rating and phase requirements before installation
2. Select appropriate top or bottom mounting configuration based on electrical panel design and space requirements
3. Install main breaker kit following NEC guidelines and local electrical codes for proper electrical protection
4. Connect phase conductors according to single-phase or three-phase system requirements using proper electrical connections
5. Test circuit breaker operation to ensure proper electrical protection functionality and system safety
6. Complete installation documentation and electrical system commissioning per professional electrical standards

Professional Applications

Ideal for:

• Commercial Power Distribution - Main electrical protection for office buildings, retail facilities, and commercial electrical systems requiring reliable 100A capacity
• Industrial Electrical Systems - Robust main breaker protection for manufacturing facilities, warehouses, and industrial power distribution applications
• Electrical Panel Upgrades - Professional electrical panel modernization projects requiring enhanced main breaker protection and system reliability
• Power Distribution Centers - Critical electrical infrastructure applications demanding dependable main circuit protection and system control
• Facility Electrical Systems - Healthcare, educational, and institutional facilities requiring professional-grade electrical protection and power management
• Electrical Contractor Projects - New construction and renovation projects requiring UL-listed main breaker protection with flexible mounting options
• Multi-Phase Applications - Electrical systems requiring both single-phase and three-phase compatibility for diverse load requirements
• Professional Electrical Installations - Applications demanding compact, reliable main breaker protection with proven Eaton electrical performance

Pow-R-Xpress Technology Advantage

The Pow-R-Xpress series represents Eaton's commitment to advanced electrical protection technology, featuring the PDD2XF circuit breaker type that delivers superior electrical performance and reliability. This main breaker kit combines compact design with robust 100A capacity, providing professional electricians with the flexibility of top and bottom mounting configurations while maintaining the electrical safety standards that facility managers and electrical contractors demand for critical power distribution applications.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton continues to lead the industry in intelligent power solutions and electrical protection technology. This main breaker kit exemplifies Eaton's commitment to electrical safety and reliability, featuring UL 67 certification and trusted performance that electricians, electrical contractors, and facility professionals worldwide depend on for their most demanding electrical power distribution and protection applications.
