Eaton Thermal-Magnetic Circuit Breaker Three-Pole 100A 22kAIC 240V Quicklag Industrial QBHW Bolt-On

Eaton Quicklag Industrial Thermal-Magnetic Circuit Breaker

Professional Three-Pole 100A Circuit Protection Equipment

The Eaton Quicklag Industrial Thermal-Magnetic Circuit Breaker delivers exceptional electrical power management and control performance for industrial and commercial electrical systems. This 100A three-pole circuit breaker provides reliable electrical protection designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Superior Electrical Protection Performance

• 100 Ampere Current Rating - Provides robust current handling capacity for high-demand industrial and commercial electrical circuits with reliable thermal-magnetic protection
• 22 kAIC Interrupt Rating - Delivers exceptional fault current interrupting capability for enhanced electrical safety and system protection in demanding applications
• Three-Pole Configuration - Ensures comprehensive protection across all three phases for balanced electrical distribution and complete circuit isolation
• 240V Voltage Rating - Optimized for standard commercial and industrial voltage applications with reliable performance and electrical safety

Professional Installation & Protection

• Bolt-On Mounting Method - Provides secure mechanical connection and reliable electrical contact for professional panel installations
• QBHW Circuit Breaker Type - Engineered for industrial applications with non-interchangeable trip characteristics for consistent protection performance
• UL Listed Certification - Meets rigorous electrical safety standards and code compliance requirements for professional electrical installations

Technical Specifications

Amperage Rating: 100A, Voltage Rating: 240V, Interrupt Rating: 22 kAIC, Number of Poles: Three-pole, Circuit Breaker Type: QBHW, Trip Type: Non-Interchangeable, Mounting Method: Bolt-on, Product Dimensions: 2.9" W x 3" H x 2.9" D, Product Weight: 1.1 lb, Certifications: UL Listed, HACR Rated for heating, air conditioning, and refrigeration applications

Installation & Usage

1. Verify electrical panel compatibility and ensure proper voltage and amperage matching for the three-pole 100A configuration
2. Turn off main power supply and verify de-energized state using appropriate electrical testing equipment before installation
3. Position the circuit breaker in the designated panel location and secure using the bolt-on mounting method for reliable connection
4. Connect phase conductors to the appropriate terminals ensuring proper torque specifications and electrical contact integrity
5. Verify proper mechanical operation and electrical continuity before energizing the protected circuit
6. Test circuit breaker operation and confirm proper protection coordination within the electrical distribution system

Professional Applications

Ideal for:

• Industrial Power Distribution - Motor control centers, industrial machinery protection, and heavy-duty electrical equipment circuits
• Commercial Electrical Systems - Office buildings, retail facilities, and commercial HVAC system protection with reliable three-phase power distribution
• Manufacturing Facilities - Production equipment protection, conveyor systems, and industrial process control applications
• HVAC Applications - Air conditioning units, heating systems, and refrigeration equipment with HACR rating compliance
• Electrical Panel Upgrades - Modernization of existing electrical distribution systems with enhanced protection capabilities
• Motor Protection Circuits - Three-phase motor starting and protection applications in industrial and commercial environments
• Electrical Safety Systems - Critical circuit protection for essential building systems and emergency power applications
• Load Center Applications - High-amperage branch circuit protection in commercial and industrial electrical distribution panels

Thermal-Magnetic Protection Advantage

The thermal-magnetic trip mechanism combines the benefits of thermal protection for overload conditions and magnetic protection for short-circuit faults, providing comprehensive electrical protection. This dual-protection technology ensures reliable circuit interruption across the full range of fault conditions while maintaining consistent performance in varying environmental conditions, making it ideal for demanding industrial and commercial electrical applications.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton delivers unmatched reliability and performance in circuit protection technology. Our commitment to electrical safety, rigorous UL certification standards, and proven performance makes Eaton the trusted choice for electricians, electrical contractors, and facility professionals worldwide. The Quicklag series represents decades of engineering excellence in industrial circuit protection, providing the dependable performance and advanced technology that electrical professionals demand for critical power distribution applications.
