Eaton Quicklag Industrial Thermal-Magnetic Circuit Breaker - Two-Pole 15A 22 kAIC 120/240V Bolt-On
Professional Industrial Circuit Protection with HACR Rating
The Eaton Quicklag Industrial Thermal-Magnetic Circuit Breaker delivers reliable two-pole circuit protection for industrial applications. This 15A unit features a robust 22 kAIC interrupt rating and operates at 120/240V with bolt-on mounting for secure installation. HACR rated and UL Listed, this thermal-magnetic breaker provides dependable overcurrent protection in demanding industrial environments.
Professional Features & Benefits
- 15A Rating: Provides precise current protection for medium-load industrial circuits and equipment.
- 22 kAIC Interrupt Rating: Delivers high fault current interruption capability for enhanced safety in industrial installations.
- Two-Pole Configuration: Offers simultaneous protection for both hot conductors in 240V applications.
- Bolt-On Mounting: Ensures secure mechanical connection and reliable contact in high-vibration industrial environments.
- HACR Rated: Certified for heating, air conditioning, and refrigeration applications with motor load compatibility.
- UL Listed: Meets rigorous safety standards for commercial and industrial electrical installations.
- Thermal-Magnetic Operation: Combines thermal overload and magnetic short-circuit protection for comprehensive circuit safety.
Technical Specifications
- Amperage Rating: 15 A
- Catalog Notes: HACR rated
- Certifications: UL Listed
- Circuit Breaker Type: QBHW
- Department: Electrical
- Interrupt Rating: 22 kAIC
- Mounting Method: Bolt-on
- Number Of Poles: Two-pole
- Product Group: Electrical
- Product Height: 4.8 in
- Product Length Depth: 3.9 in
- Product Subgroup: Circuit Breaker
- Product Type: Thermal Magnetic Circuit Breaker
- Product Weight: .55 lb
- Product Width: 2.1 in
- Quantity: 7
- Trip Type: Non-Interchangeable
- Voltage Rating: 120/240 V
Installation & Operation
- Mount the unit in a suitable location with appropriate clearance and access for connections and service.
- Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
- Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
- Configure any available load management or control features as supported by the provided specifications.
- Test automatic transfer or operational functionality and verify proper performance before placing into service.
- Complete final inspection and follow ongoing maintenance practices appropriate to the product category.
Professional Applications
- Industrial Manufacturing Facilities
- Commercial HVAC Systems
- Motor Control Centers
- Distribution Panels
- Refrigeration Equipment
- Process Control Systems
- Heavy Equipment Protection
Why Choose Eaton Quality?
Eaton Quicklag circuit breakers deliver proven reliability with UL Listed certification and HACR rating for specialized applications. The compact 4.8" x 3.9" x 2.1" design and lightweight .55 lb construction provide flexible installation options while maintaining robust 22 kAIC interrupt capability for demanding industrial environments.
Manufacturer Resources
Product Specs
- Amperage Rating:
- 15 A
- Catalog Notes:
- HACR rated
- Certifications:
- UL Listed
- Circuit Breaker Type:
- QBHW
- Interrupt Rating:
- 22 kAIC
- Mounting Method:
- Bolt-on
- Number Of Poles:
- Two-pole
- Product Height:
- 4.8 in
- Product Length Depth:
- 3.9 in
- Product Weight:
- .55 lb
- Product Width:
- 2.1 in
- Trip Type:
- Non-Interchangeable
- Voltage Rating:
- 120/240 V
- Product Type:
- Thermal Magnetic Circuit Breaker
- Product Group:
- Electrical
- Product Subgroup:
- Circuit Breaker
- Department:
- Electrical
- Item Quantity:
- 7
