Eaton Molded Case Circuit Breaker 30A Three-Pole 600V Series C F-Frame HFD Fixed Thermal-Magnetic

Eaton Molded Case Circuit Breaker 30A Three-Pole 600V Series C F-Frame HFD Fixed Thermal-Magnetic

Professional Industrial Circuit Protection Equipment

The Eaton Series C Molded Case Circuit Breaker delivers exceptional electrical power protection and control performance for industrial and commercial electrical systems. This 30A three-pole circuit breaker provides reliable electrical protection with 600 Vac/250 Vdc voltage rating and 100 kAIC interrupt capacity designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Superior Circuit Protection Performance

• 30 Ampere Current Rating - Provides precise overcurrent protection for medium-duty industrial and commercial electrical circuits with reliable thermal-magnetic trip operation
• Three-Pole Configuration - Delivers simultaneous protection across all three phases for balanced three-phase electrical systems and motor protection applications
• 600 Vac/250 Vdc Voltage Rating - Handles high voltage applications in industrial power distribution systems with dual AC/DC voltage capability for versatile installations
• 100 kAIC Interrupt Rating at 240 Vac - Provides exceptional fault current interrupting capacity for high-fault current industrial electrical systems and critical power distribution applications

Advanced Trip Technology & Construction

• Fixed Thermal-Magnetic Trip Type - Combines thermal overload protection with magnetic short-circuit protection for comprehensive electrical fault detection and circuit isolation
• Series C F-Frame Design - Features Eaton's proven F-frame molded case construction for durability and reliable performance in demanding industrial environments
• HFD Circuit Breaker Type - Engineered with high-performance interrupting technology for superior arc extinction and electrical safety in critical applications

Professional Installation & Safety

• Load Side Terminal Configuration - Provides secure electrical connections with professional-grade terminals designed for reliable power distribution and easy maintenance access
• UL Listed Certification - Meets rigorous electrical safety standards and code compliance requirements for professional electrical installations and inspections
• Complete Breaker Assembly - Ready-to-install molded case circuit breaker with all components integrated for efficient electrical panel installation and commissioning

Technical Specifications

Current Rating: 30 Amperes | Voltage Rating: 600 Vac, 250 Vdc | Number of Poles: Three-pole | Interrupt Rating: 100 kAIC at 240 Vac | Series: Series C | Frame: F-frame | Circuit Breaker Type: HFD | Trip Type: Fixed thermal, fixed magnetic | Frequency Rating: 50/60 Hz | Terminals: Load side | Certification: UL Listed | Dimensions: 6" H x 4.13" W x 3.38" D | Weight: 4.3 lbs

Installation & Usage

1. Verify electrical panel compatibility with F-frame molded case circuit breaker mounting requirements and available space
2. Ensure power is completely disconnected and locked out before beginning circuit breaker installation procedures
3. Mount the circuit breaker securely in the electrical panel using proper mechanical connections and alignment
4. Connect load-side conductors to terminals following NEC requirements and manufacturer torque specifications
5. Verify proper three-pole operation and phase sequence before energizing the protected electrical circuit
6. Test circuit breaker operation and confirm proper thermal-magnetic trip function before placing system in service

Professional Applications

Ideal for:

• Industrial Power Distribution - Motor control centers, industrial switchgear, and three-phase power distribution systems requiring high interrupt capacity
• Commercial Electrical Systems - Office buildings, retail facilities, and commercial power panels with medium-duty electrical loads and equipment protection
• Manufacturing Facilities - Production equipment protection, machinery circuits, and industrial process control electrical systems
• Three-Phase Motor Protection - HVAC equipment, industrial motors, and rotating machinery requiring balanced three-pole circuit protection
• High-Voltage Applications - 480V and 600V electrical systems, industrial transformers, and high-voltage distribution equipment
• Critical Power Systems - Emergency power distribution, backup generator systems, and uninterruptible power supply applications
• Electrical Panel Upgrades - Modernization of existing electrical panels and replacement of obsolete circuit protection equipment
• Code Compliance Projects - New construction and electrical system upgrades requiring UL Listed circuit protection devices

Series C Technology Advantage

Eaton's Series C molded case circuit breakers feature advanced thermal-magnetic trip technology that provides precise overcurrent protection with reliable operation across a wide range of electrical fault conditions. The fixed thermal element responds to sustained overloads while the magnetic element provides instantaneous protection against short circuits, delivering comprehensive electrical system protection for professional applications.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton delivers the proven reliability and advanced technology that electrical professionals trust worldwide. Our molded case circuit breakers are engineered to meet the demanding requirements of industrial and commercial electrical systems, backed by comprehensive UL listings and rigorous quality testing. From electrical contractors to facility managers, professionals choose Eaton for dependable circuit protection that ensures electrical safety and system reliability in critical applications.
