Falcon H2101 Entrance Interconnected Lock — Single Cylinder Deadbolt, Grade 2
The Falcon H2101 is a commercial-grade interconnected lock that pairs a single cylinder deadbolt with a lever-handle latchset in one integrated unit. A single interior turn of the lever simultaneously retracts both the latch and the deadbolt, satisfying Life Safety single-motion egress requirements without a second operation. Designed for multi-family entry doors, corridor access points, and fire-rated openings, the H2101 is available in two cylinder configurations — conventional 6-pin G keyway (P6) and SFIC prep less core (BD) — across seven lever styles and six finishes.
Key Specifications
- Standard: ANSI/BHMA A156.25, Grade 2
- Fire Rating: 3-hour UL listed; UL 1-1/2 Hour B Label
- Backset: 2-3/8" or 2-3/4" (field selectable)
- Door Thickness: 1-3/4" to 2" standard; 1-3/8" available
- Cylinder Options: P6 — Conventional 6-pin G keyway; BD — SFIC prep, less core
- Handing: Field reversible
- Handle Type: Lever (Avalon, Boardwalk, Broadway, Dane, Latitude, Longitude, Quantum)
- Keyed Function: Single cylinder (exterior key, interior thumbturn)
- Finish Options: 605 Bright Brass, 619 Satin Nickel, 622 Matte Black, 625 Bright Chrome, 626 Satin Chrome, 643E Aged Bronze
- Application: Commercial / Multi-Family
Why the H2101 Works for Commercial Openings
- Single-Motion Egress: Interconnected mechanism retracts latch and deadbolt simultaneously — meets IBC and NFPA 101 egress requirements without a second operation.
- 3-Hour Fire Rating: UL listed for fire-rated door assemblies; suitable for stairwell and corridor openings requiring B-label hardware.
- SFIC-Ready Option: BD cylinder prep accepts Small Format Interchangeable Core for facilities on Best, Arrow, or compatible SFIC master-key systems — no re-keying the lock body when rekeying the building.
- Field Reversible: Handing is set on-site; no need to specify left- or right-hand at order time.
- Finish Compatibility: Finish codes align with Falcon and Schlage product lines for consistent hardware schedules across a project.
Typical Applications
- Multi-family residential entry and unit doors
- Corridor and stairwell access in commercial office buildings
- Educational facility interior and exterior doors
- Healthcare and institutional room access
- Government and municipal building entrances
- Retail and hospitality security doors
Installation & Documentation
The H2101 installs into a standard cylindrical prep. Verify door thickness, stile width, and backset before ordering. Download the Falcon H2 Series Data Sheet and Falcon Locks Catalog (linked above) for full template dimensions, torque specs, and trim compatibility charts. For SFIC installations, confirm core compatibility with your master-key system supplier before specifying the BD cylinder option.
Manufacturer Resources
Falcon Locks Catalog
Product Specs
- Maximum Purchase:
- 999 units
- Series:
- H2 Series
- Grade:
- Grade 2
- Handle Type:
- Lever
- Keyed Function:
- Single Cylinder
- Keyed:
- Yes
- Electronic:
- No
- Product Type:
- Deadbolts
- Commercial/Residential:
- Commercial
- Lock Function:
- Entrance
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Deadbolts
- Subcategory:
- Deadbolts
- Product Attribute:
- Cylindrical Locks
- Product Function:
- Entrance
- Door Hand Direction:
- Field Reversible
- Product Category:
- Mechanical Locks
- Department:
- Door Hardware
Falcon H2101P6 DAN 626 – Frequently Asked Questions
1) What applications is the Falcon H2101 entrance lock designed for?
The H2101 is designed for entrance doors requiring both passage and security functions. Ideal for commercial buildings, offices, and institutional applications where interconnected operation is needed.
2) How does the interconnected function work?
The interconnected design allows the deadbolt to automatically retract when the lever handle is turned from inside. This provides quick egress while maintaining security from outside entry.
3) What door thickness does this lock accommodate?
Standard door thickness is typically 1-3/4". Verify your specific door thickness and check manufacturer specifications for exact compatibility before installation.
4) Is this lock handed or universal?
Most Falcon entrance locks are field-reversible for left or right hand doors. Confirm handing requirements during ordering and follow manufacturer instructions for proper configuration.
5) What finish options are available for the H2101?
Falcon typically offers multiple finish options including satin chrome, polished brass, and oil-rubbed bronze. Check product specifications for available finishes in this model.
6) What does Grade 2 security rating mean?
Grade 2 meets ANSI standards for medium-duty commercial applications. Provides good security and durability for office buildings and light commercial use.
7) Can this lock be keyed to match existing systems?
Yes, Falcon locks can typically be keyed alike or integrated into master key systems. Consult with a locksmith for proper keying arrangements.
8) What tools are needed for installation?
Basic installation requires drill, hole saw, chisel, screwdriver, and measuring tools. Follow manufacturer template for precise hole locations and sizes.
9) How do I adjust the latch or strike alignment?
Minor adjustments can be made by filing the strike plate or adjusting door alignment. For proper operation, ensure door and frame are square and gaps are consistent.
10) Are there other Falcon entrance lock models available?
Falcon offers various entrance lock configurations and grades. Browse our Falcon hardware selection for alternative models and functions.
11) Will this lock work in extreme weather conditions?
Grade 2 locks are designed for standard environmental conditions. For exterior doors in harsh climates, ensure proper door sealing and consider weather-resistant finishes.
