Hager 2-679-0612 PIR Egress Sensor with Adjustable Detection Pattern

Hager 2-679-0612 PIR Egress Sensor with Adjustable Detection Pattern

Professional Request-to-Exit Motion Detection Solution

The Hager 2-679-0612 PIR Egress Sensor combines passive-infrared detection technology with dual relay outputs for professional request-to-exit applications in access-controlled door systems. This UL 294 listed sensor features an adjustable detection range of 7' to 15' with pressure sense technology and tri-failsafe operation. Operating on 12/24VDC/VAC power with maximum 26 mA consumption, the unit provides SPDT dry contact outputs rated at 2 amp @ 30VDC for reliable integration with magnetic locks and access control systems.

Professional Features & Benefits

• Adjustable Detection Range: 7' to 15' detection pattern allows customization for specific door and room configurations.
• Dual Relay Outputs: SPDT dry contact relays rated at 2 amp @ 30VDC with both EMF spike protected and non-EMF protected outputs for versatile system integration.
• Code Compliant Operation: Fail-safe mode releases locks when power is interrupted, meeting national fire and building code requirements for access controlled egress doors.
• Flexible Power Options: 12/24VDC/VAC operation with low 26 mA maximum power consumption for efficient system integration.
• Tri-Failsafe Technology: Pressure sense technology with tri-failsafe operation ensures reliable detection and system response.
• Adjustable Timing Controls: Relay latch duration adjustable from 0.5 second to 64 seconds with resettable or non-resettable timer modes.
• Professional Construction: High impact ABS plastic housing rated for -20° to 120°F operating temperature range for indoor commercial applications.
• UL Listed Certification: UL 294 listing ensures compliance with professional access control standards and code requirements.
• Wall or ceiling mounted with an adjustable detection pattern
• Detection range of 7'- 15'
• Pressure sense technology; Tri-failsafe

Technical Specifications

• Accessories: 2973 Exit Switch required when using PIR sensor with magnetic locks to maintain code compliance.
• Applications: The Hager PIR Motion Sensor combines a passive-infrared detector with relay outputs to allow control of door ingress and egress in request-to-exit (REX) applications
• Certifications: UL Listed 294
• Commercial/Residential: Commercial
• Finishes: White - 2-679-0611; Black - 2-679-0612
• Functions: Relay Latch Duration - Adjustable from 0.5 second to 64 seconds; Timer Modes: resettable (cumulative) or non-resettable (counting); Modes: Fail Safe (Doors Unlocked) or Fail Secure (Doors Locked)
• Material: High impact ABS plastic
• Size: 1.75" - Height; 7" - Width; 1.88" - Depth
• Subcategory: Door Position Switches & Alarms
• Warranty: 1 Year

Installation & Operation

1. Verify electrical requirements match available power supply. Confirm 12/24VDC/VAC voltage and current capacity before proceeding.
2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
5. Configure operational settings including fail-safe/fail-secure mode and relay latch duration per application requirements.
6. Restore power and test all functions including normal operation, detection response, and integration with connected magnetic locks and access control systems.
7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

• Commercial Building Access Control Systems
• Healthcare Facility Egress Compliance
• Educational Institution Safety Systems
• Retail Security and Loss Prevention
• Industrial Facility Monitoring
• Government and Municipal Buildings
• Emergency Exit Code Compliance

Code Compliance Features

The Hager 2-679-0612 operates in code compliant fail-safe mode, automatically releasing locks when power to the PIR sensor is interrupted. For applications using magnetic locks, the unit requires the 2973 exit switch for secondary release to maintain full code compliance with national fire and building code requirements for access controlled egress doors.

Why Choose Hager Quality?

Hager PIR egress sensors deliver professional-grade reliability with UL 294 listing and high impact ABS plastic construction rated for demanding commercial temperature ranges. The tri-failsafe pressure sense technology and dual relay outputs provide dependable performance in critical access control applications. Backed by a 1 year manufacturer warranty for added confidence and protection.
