Hager 3440 Grade 1 Cylindrical Withnell Privacy Lever Lock

Hager 3440 Grade 1 Cylindrical Privacy Lever Lock

(No reviews yet) Write a Review

Model: 3440 WTN 26D
Selected Lever Type is
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$409.11
$266.94
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Hager 3440 Grade 1 Cylindrical Privacy Lever Lock

Commercial-Grade Privacy Lock Solution

The Hager 3440 Grade 1 Cylindrical Privacy Lever Lock features the distinctive Withnell lever design and delivers professional-grade security for commercial, industrial, and institutional environments. This ANSI F76A privacy function lock accommodates door thickness from 1-3/8" to 2" with standard 2-1/8" cross bore and 1" edge bore preparation. Built to Grade 1 standards, this cylindrical lock provides reliable privacy control with push-button locking from inside and emergency release capability from outside.

Professional Features & Benefits

  • Door Compatibility: Fits door thickness range of 1-3/8" to 2" with standard 2-1/8" cross bore and 1" edge bore preparation for versatile installation options.
  • Grade 1 Construction: Engineered to withstand the most abusive commercial, industrial, and institutional environments with superior durability and performance.
  • Privacy Function Operation: ANSI F76A privacy function with latchbolt operated by lever from either side, push-button inside locking, and emergency release outside capability.
  • Clean Installation Design: No exposed mounting screws provide a professional appearance and enhanced tamper resistance.
  • Withnell Lever Design: Distinctive WTN Withnell lever styling combines functionality with professional aesthetics for commercial applications.
  • Standard Backset: 2-3/4" backset distance accommodates most standard door preparations and frame configurations.
  • Manufacturer Warranty: 5 Year warranty coverage for added confidence and protection in demanding commercial applications.

Technical Specifications

  • Backsets: 2-3/4"
  • Commercial/Residential: Commercial
  • Door Strike: ASA Strike
  • Door Thickness: 1-3/8" to 2"
  • Functions: Single Cylinder
  • Grade: Grade 1
  • Handle Type: Lever
  • Keyed: No
  • Lock Type: Cylindrical
  • Subcategory: Cylindrical Locks
  • Warranty: 5 Year

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness range of 1-3/8" to 2", 2-1/8" cross bore diameter, and 1" edge bore diameter.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for proper alignment.
  3. Prepare door by drilling required 2-1/8" cross bore and 1" edge bore holes as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the cylindrical lock to door per manufacturer torque specifications with 2-3/4" backset positioning.
  5. Adjust operational components for proper alignment, latching, and smooth lever operation with privacy function testing.
  6. Test device operation to verify proper privacy function including push-button locking, emergency release, and lever operation from both sides. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings
  • Hospitality and Hotel Properties

Why Choose Hager Quality?

Hager 3440 Series cylindrical locks deliver professional-grade reliability with Grade 1 construction engineered to withstand the most abusive commercial, industrial, and institutional environments. Backed by a comprehensive 5 Year warranty, this privacy lock provides dependable performance where reliable access control and emergency release capability are essential for occupant safety and security.

Product Specs

Warranty:
5 Year
Keyed Function:
Single Cylinder
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Subcategory:
Cylindrical Locks
Keyed:
No
Commercial/Residential:
Commercial
Lock Type:
Cylindrical
Handle Type:
Lever
Grade:
Grade 1
Product Attribute:
Cylindrical Locks
Product Model:
3440
Product Function:
Privacy/Bed/Bath
Door Thickness Range:
1-3/8" to 2"
Door Strike:
ASA Strike
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

Hager 3440 WTN 26D – Frequently Asked Questions

1) Will the Hager 3440 privacy lever fit a 1-3/8 inch door, or does it need a 1-3/4?
The Hager 3440 cylindrical privacy lever covers 1-3/8 inch through 2 inch doors on the same lock, so it works on older 1-3/8 interior doors and on standard 1-3/4 commercial doors without ordering a different part. That range is wider than a lot of commercial locks, which start at 1-3/4.
2) What door prep does the Hager 3440 lever lock need - bore sizes and backset?
Standard commercial bored prep: 2-1/8 inch cross bore, 1 inch edge bore, and a 2-3/4 inch backset. If the door is already bored for a 2-3/8 inch backset, the 3440 will not line up, since 2-3/4 is the only backset it comes in. An ASA strike is what it latches into.
3) Does the Hager 3440 take a key, and how does someone get in during an emergency?
No key and no cylinder. The 3440 is a non-keyed ANSI F76A privacy function: the lever retracts the latch from either side, a push button on the inside locks it, and the outside has an emergency release for staff to open the door in a bathroom or bedroom emergency. If you need key control on that opening, this is the wrong function.
4) What is the closest Grade 1 privacy alternative to the Hager 3440 if a knob is acceptable instead of a lever?
The Arrow MK02-TA is a Grade 1 privacy cylindrical lock with a Tudor knob and a fire rating, covering the same Privacy/Bed/Bath function as the Hager 3440. The difference is the trim and the door range: the Hager 3440 is a lever set fitting 1-3/8 inch to 2 inch doors, while the MK02-TA is a knob set for doors 1-3/4 inch to 2 inch. On a facility standardizing on lever trim for ADA reasons the 3440 is the one that carries the lever; where a knob is acceptable and a fire rating is called out on the drawing, the MK02-TA answers that.
5) The door does not need to lock at all - what takes the place of a Hager 3440 on a hall or closet opening?
Drop to a passage lever and keep the same grade. The Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, fire rated, fitting doors 1-3/8 inch to 2-1/4 inch, and the Falcon T101 is a Grade 1 heavy duty passage lever as well. The Corbin Russwin CL3110 is a Grade 1 vandal resistant passage lever, fire rated, for 1-3/4 inch to 2 inch doors. All three latch without locking; the Hager 3440 adds the push-button inside locking and outside emergency release that a bed or bath opening needs.
6) The opening needs to be keyed - what replaces a Hager 3440 when privacy is not enough?
The Hager 3440 is non-keyed, so a keyed opening needs a different function. The Dexter C1000 Series offers Grade 1 keyed cylindrical levers in Entry/Office, Classroom, and Classroom Security functions for doors 1-3/8 inch to 1-3/4 inch, and a Grade 1 Asylum function for 1-3/8 inch to 2 inch doors. The Cal-Royal AG05 is a Grade 2 storeroom lever with a deadlocking latchbolt for 1-3/8 inch to 1-3/4 inch doors. Keep the 3440 on bed and bath doors and move to a keyed function where an office, storeroom, or classroom is being secured.
7) For a behavioral health or utility room, is a Hager 3440 the right lock?
No - those openings call for an asylum function. The Dexter C1000 Series Asylum (F87) is a Grade 1 cylindrical lock for doors 1-3/8 inch to 2 inch, and the Arrow MK33-BD-CS is a Grade 2 heavy duty asylum lock with a ball knob and conventional cylinder in Schlage C keyway. The Hager 3440 is an ANSI F76A privacy function with push-button inside locking, which puts control of the door with the occupant rather than with staff.
8) Which cylindrical lever sets carry a fire rating if a Hager 3440 opening turns out to be on a rated wall?
Two Grade 1 cylindrical peers carry a stated fire rating: the Corbin Russwin CL3110 passage lever for doors 1-3/4 inch to 2 inch, and the Falcon K101 passage lever for doors 1-3/8 inch to 2-1/4 inch. The Arrow MK02-TA is fire rated as well and is a Grade 1 privacy function, though with a Tudor knob rather than a lever. On a rated opening that also needs privacy and lever trim, the MK02-TA is the fire-rated privacy peer and the trim style is the trade-off to weigh.
9) Is a Grade 1 privacy lever worth it for restrooms, or is a Grade 2 enough?
Grade 1 is the heaviest of the three ANSI/BHMA cylindrical grades and is what the 3440 is built to, aimed at commercial, industrial and institutional traffic. For a public restroom or a patient room that gets hundreds of cycles a day, that is the tier that holds up. For a low-traffic private office or an apartment bedroom door, a Grade 2 privacy lock such as the Arrow MK02-TA, or a Grade 3 like the Kwikset 300BRNL Breton privacy lever, covers the same function at a lighter duty level.
10) What lever styles and finishes does the Hager 3440 come in?
Three lever designs, Withnell, Archer and August, each available in four finishes: 613 satin bronze oil-rubbed, 626 satin chrome, 606 satin brass, and black. Every lever/finish pairing exists, so if a building is standardized on 626 satin chrome you can hold that finish and still pick the lever shape that matches the other openings.
11) I need a matching passage lever for the hall doors next to a bathroom with a Hager 3440 - does the lever style carry across?
The 3440 is privacy only; it has no passage version in the same model number. For an aesthetic match across a corridor you are looking at another Grade 1 cylindrical passage lever, for example the Corbin Russwin CL3110 passage/closet (1-3/4 to 2 inch doors), the Falcon K101 (1-3/8 to 2-1/4 inch), or the Design Hardware X75 flat lever for 1-3/4 inch doors. None of those carry Hager's Withnell, Archer or August lever shapes, so the trim will read as a different family even if the function is right.
12) Is the Hager 3440 lever handed - do I need to specify left or right?
Handing is not part of the order on the 3440. The two things to specify are lever design (Withnell, Archer or August) and finish. Everything else, backset at 2-3/4 inches and the ASA strike, is fixed.
13) Can I use a cylindrical privacy lever like the Hager 3440 on a patient room or holding room door?
For a normal patient room or staff restroom, yes, that is what the F76A privacy function with outside emergency release is for. For a behavioral health or detention-style opening you want an asylum or institutional function instead, where the door is operated by key from both sides and cannot be locked by the occupant. The Dexter C1000 asylum (F87) or the Arrow MK33-BD-CS asylum lock cover that case.
14) Which lever set matches a Hager 3440 on an inactive leaf or a false door that only needs trim?
Use a dummy trim. The BEST 9K Series 1DT is a Grade 1 non-keyed heavy duty single dummy trim cylindrical lever, matching the Hager 3440's Grade 1 tier, and the BEST 7KC Series 1DT is the medium duty Grade 2 equivalent. The Accentra 455LN Augusta is a Grade 1 heavy duty single dummy cylindrical lever in the 5400 Series. A dummy carries no latch and does not operate - the Hager 3440 is the working privacy set for the leaf that actually latches.
15) Is a keypad lever an alternative to a Hager 3440 on a restroom or staff door?
It solves a different problem. The Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1 3/16 inch to 2 inch, and the Lockey 1150 is a heavy duty mechanical keypad lever set with passage function and adjustable backset for 1-1/8 inch to 2 inch doors. Those control who gets in with a code. The Hager 3440 controls occupancy from inside with a push button and gives staff an emergency release from outside - what a bath or bed door needs.
16) Does a Cal-Royal AG03 classroom lever share the same backset as a Hager 3440?
Yes on backset. The Cal-Royal AG03 is a Grade 2 classroom lever with a 2-3/4 inch backset and a 6-pin Schlage C keyway keyed different, and the Hager 3440 also uses a 2-3/4 inch backset. The prep differs in function rather than layout: the AG03 is keyed, while the 3440 is non-keyed privacy. The Cal-Royal AG00 entrance lever in the same family uses a 2-3/8 inch backset, so it will not land on a door bored for 2-3/4 inch.
17) Do the screws show on the Hager 3440 rose, and does that matter for tamper resistance?
No exposed mounting screws on the 3440. On a restroom or patient-room door that is worth something beyond looks, there is nothing on the outside face for an occupant to back out with a screwdriver.
18) Lever or knob for a Hager bathroom lock - which should I be ordering?
The 3440 is the lever version, and a lever is what ADA-governed openings and most commercial specs call for because it operates without grasping or twisting. Knob privacy locks still exist in the same grade tier, for instance the Arrow MK02-TA tudor knob, and are usually chosen for residential or back-of-house doors where lever projection is a problem.
19) What is the Grade 2 version of a heavy commercial privacy lever like the Hager 3440?
There is no direct Grade 2 privacy lever peer, but the Grade 2 cylindrical lever tier is where the Falcon B101 passage lock (medium duty, non-handed), the Accentra 5301LN Augusta passage lever in the 5300 Series, and the Design Hardware J75 passage lever for 1-3/4 inch doors sit. Those are passage, not privacy - they latch without locking. If the opening genuinely needs the push-button privacy lock, stay with the Hager 3440 at Grade 1 rather than dropping tier.
