Hager 3600 Series 3653 Grade 1 Entry/Office Cylindrical Lock with Conventional Cylinder

Hager 3600 Series 3653 Grade 1 Entry/Office Cylindrical Lock with Conventional Cylinder

Professional-Grade Commercial Cylindrical Lock Solution

The Hager 3600 Series 3653 Grade 1 Entry/Office Cylindrical Lock delivers commercial-grade security with BHMA Grade 1 certification for demanding applications. This non-handed cylindrical lock features adjustable 2-3/8" to 2-3/4" backsets and accommodates door thickness from 1-3/8" to 1-3/4". Built with wrought brass, bronze, and stainless steel exposed trim components, this lock provides reliable performance with UL/cUL listing for up to 3-hour fire rating applications.

Professional Features & Benefits

• Adjustable Backset Configuration: 2-3/8" to 2-3/4" (60mm - 70mm) adjustable backset accommodates various door preparations and installation requirements.
• Versatile Door Compatibility: Designed for door thickness range of 1-3/8" to 1-3/4" (35mm - 45mm) for standard commercial and residential applications.
• Grade 1 Commercial Performance: BHMA Certified ANSI A156.2, Series 4000, Grade 1 rating ensures heavy-duty performance for high-traffic commercial environments.
• Premium Construction Materials: Wrought brass, bronze, and stainless steel exposed trim with zinc-based plated levers provide exceptional durability and corrosion resistance.
• Fire-Rated Compliance: UL/cUL Listed for all functions up to 3 hours "A" label single doors with UL10C Positive Pressure Rating for fire safety applications.
• ADA Accessibility Compliance: Meets ANSI A117.1 Accessibility Code requirements for barrier-free access in commercial facilities.
• Professional Installation Design: Non-handed configuration with no exposed mounting screws provides clean appearance and simplified installation.
• Manufacturer Warranty: Five-Year warranty coverage for added confidence and long-term protection.

Technical Specifications

• Applications: Medium Duty Commercial; Heavy Duty Residential
• Backsets: Adjustable 2-3/8" - 2-3/4" (60mm - 70mm)
• Certifications: ADA Compliant ANSI A117.1 Accessibility Code; UL/cUL Listed for all functions up to 3 hours "A" label single doors; UL10CPositive Pressure Rated; BHMA Certified ANSI A156.2, Series 4000, Grade 2
• Commercial/Residential: Commercial
• Door Strike: ASA Strike
• Door Thickness: 1-3/8" to 1-3/4"
• Finishes: US3, US4, US10B, US26, US26D
• Functions: Single Cylinder
• Grade: Grade 1
• Handle Type: Lever
• Keyed: Yes
• Lock Type: Cylindrical
• Notes: No exposed mounting screws; Non-handed
• Options: Split Finish
• Series: 3600 Series
• Strikes: 1-1/4" x 4-7/8" (32 mm x 124 mm) ASA strike; Optional strikes available
• Subcategory: Cylindrical Locks
• Warranty: Five-Year

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness of 1-3/8" to 1-3/4", backset adjustment of 2-3/8" to 2-3/4", and handing as applicable to this product.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Hager Quality?

Hager 3600 Series cylindrical locks deliver professional-grade reliability with wrought brass, bronze, and stainless steel construction rated for Grade 1 commercial performance. Five-Year warranty coverage and comprehensive UL/cUL fire rating certifications provide added confidence for demanding applications. Engineered for commercial environments where dependable security and accessibility compliance are essential.
