Ives 347 Dual Adjustable Ball Catch with Square Corners - Brass Construction

Ives 347 Dual Adjustable Ball Catch with Square Corners - Brass Construction

Professional Door Latch Solution for Interior Applications

The Ives 347 Dual Adjustable Ball Catch features brass construction with square corners, designed for lower frequency opening applications including cabinets and small interior doors. This professional-grade catch includes an adjustable threaded barrel that compensates for various door clearances and adjustable spring tension for customized operation. The free rolling ball mechanism ensures smooth, positive and trouble-free action, while rounded corners on the strike lip provide enhanced safety.

Professional Features & Benefits

• Precision Dimensions: Door strike measures 1-3/8" width by 2-1/8" height with face plate at 1" width by 2-1/8" height for accurate installation planning.
• Dual Adjustment System: Adjustable threaded barrel compensates for various door clearances while adjustable spring tension allows customization for specific applications.
• Smooth Operation: Free rolling ball design ensures positive engagement and trouble-free action for reliable door retention.
• Brass Construction: Durable brass substrate provides long-lasting performance and corrosion resistance for interior applications.
• Safety Design: Rounded corners on strike lip reduce injury risk during installation and operation.
• ANSI/BHMA Compliance: Meets ANSI/BHMA A156.9, B23013 standards for quality assurance and professional applications.
• Complete Installation Kit: Units packed with wood screws for immediate installation without additional hardware purchases.

Technical Specifications

• ANSI/BHMA: ANSI/BHMA A156.9, B23013
• Commercial/Residential: Residential
• Department: Door Hardware
• Door Strike: W: 1-3/8", H: 2-1/8"
• Face Plate: W: 1", H: 2-1/8"
• Product Category: Door Trim and Accessories
• Product Group: Door Trim and Accessories
• Product Model: 347
• Product Subgroup: Door Latches and Catches
• Product Substrate: Brass
• Product Type: Ball Catches
• Subcategory: Latches, Catches and Bolts

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Cabinet Door Retention Systems
• Small Interior Door Applications
• Residential Door Hardware
• Light-Duty Door Closure Solutions
• Interior Architectural Hardware
• Custom Millwork Projects

Why Choose Ives Quality?

Ives ball catches deliver professional-grade reliability with brass construction and ANSI/BHMA A156.9 compliance for demanding residential applications. The dual adjustable design with free rolling ball mechanism provides smooth, positive action rated for lower frequency opening applications. Engineered for dependable performance where reliable door retention is essential without security requirements.
