Ives Ives FS434 Steel Angle Door Stop, Zinc Plated Finish FS4342C

Ives FS434 Steel Angle Floor Stop with Zinc Plated Finish for Light Duty Applications

(3 reviews) Write a Review

Model: FS4342C

In Stock (leaves warehouse same day if ordered before 3pm ET)

$14.10
$6.99
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Ives FS434 Steel Angle Floor Stop with Zinc Plated Finish for Light Duty Applications

Professional Floor-Mounted Door Stop Solution

The Ives FS434 Steel Angle Floor Stop provides reliable door control for undercut doors up to 1-1/2" with durable steel construction and zinc plated finish. This light duty floor stop features soft, resilient black rubber protection and comes complete with fasteners for both masonry and wood applications. Measuring H: 2-5/8", W: 1-1/2", L: 2-3/4", this professional-grade door stop meets ANSI/BHMA 156.16 standards for commercial applications.

Professional Features & Benefits

  • Door Compatibility: Designed for undercut doors up to 1-1/2" thickness for versatile installation options.
  • Compact Dimensions: H: 2-5/8", W: 1-1/2", L: 2-3/4" profile provides effective door stopping without excessive floor space requirements.
  • Durable Steel Construction: Steel substrate with zinc plated finish delivers long-lasting performance in commercial environments.
  • Non-Marring Protection: Soft, resilient black rubber contact surface protects door finish and prevents damage during contact.
  • Complete Installation Package: Includes fasteners for light duty masonry and wood applications for immediate installation capability.
  • ANSI/BHMA Compliance: Meets ANSI/BHMA 156.16 standards ensuring professional-grade performance and reliability.
  • Wall and Frame Protection: Prevents door, wall, and frame damage by stopping doors from opening too far and hitting adjacent surfaces.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Duty Level: Light Duty
  • Package Includes: Fasteners for light duty masonry and wood applications
  • Product Category: Door Trim and Accessories
  • Product Dimension: H: 2-5/8", W: 1-1/2", L: 2-3/4"
  • Product Group: Door Trim and Accessories
  • Product Model: FS434
  • Product Subgroup: Door Stops, Holders, Silencers & Bumpers
  • Product Substrate: Steel
  • Product Type: Door Stops - Angle Stops
  • Subcategory: Stops

Installation & Operation

  1. Review manufacturer specifications and verify floor surface is suitable for mounting. Confirm door swing clearance and stop positioning requirements.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on floor surface at desired door stop position.
  3. Prepare floor surface by drilling required holes using appropriate drill bits for masonry or wood substrate as applicable.
  4. Install mounting hardware using provided fasteners and secure the floor stop per manufacturer torque specifications.
  5. Test door operation to verify proper stopping function and rubber contact alignment with door bottom edge.
  6. Make final position adjustments as needed to ensure optimal door stopping performance. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Ives Quality?

Ives door stops deliver professional-grade reliability with steel construction and zinc plated finish designed for demanding commercial applications. Meeting ANSI/BHMA 156.16 standards, this floor stop provides dependable door control while protecting doors, walls, and frames from damage. Engineered with non-marring rubber components and complete fastener packages for immediate installation capability.

Manufacturer Resources

Ives Full Line Catalog

Product Specs

Product Group:
Door Trim and Accessories
Duty Level:
Light Duty
Package Includes:
Fasteners for light duty masonry and wood applications
Subcategory:
Stops
Product Subgroup:
Door Stops, Holders, Silencers & Bumpers
Commercial/Residential:
Commercial
Product Type:
Door Stops - Angle Stops
Product Model:
FS434
Product Dimension:
H: 2-5/8", W: 1-1/2", L: 2-3/4"
Product Category:
Door Trim and Accessories
Product Substrate:
Steel
Department:
Door Hardware

Ives FS4342C – Frequently Asked Questions

1) Will the Ives FS434 floor stop work with a door that has a large undercut?
The FS434 angle floor stop handles undercut doors up to 1-1/2 inches. Measure from the finished floor to the bottom of the door leaf: if that gap is more than 1-1/2 inches, the rubber bumper sits below the door edge and the door rides over it instead of stopping. The stop itself measures H 2-5/8 in., W 1-1/2 in., L 2-3/4 in., so on a bigger undercut you want a taller floor stop or a wall-mounted bumper instead.
2) Do I need to buy anchors separately for an Ives FS434 floor stop, or does it come with fasteners?
Fasteners for light duty masonry and wood come in the box, so a concrete slab or a wood subfloor is covered without a separate anchor order. You drill the floor to suit the substrate and set the stop with what is supplied. Hollow or thin flooring (tile over a void, raised access panels) is outside what these light duty fasteners are meant for, and that job needs an anchor chosen for the floor build-up.
3) Is the Ives FS434 angle floor stop rated for a commercial building, or is it a residential part?
Commercial, but at the light duty end of the range. The FS434 is a steel angle floor stop with a zinc plated finish, and it suits office doors, tenant suite doors, classrooms, and similar openings where the door is not being thrown open hard all day. High-traffic entrances, doors on closers with heavy swing, or anywhere the leaf gets kicked open should get a heavy duty stop rather than this one.
4) Angle floor stop versus a wall bumper: which one should I use on this door?
An angle floor stop like the FS434 mounts to the floor in the door's swing path and catches the leaf near its bottom edge, which is the answer when the wall behind the door is glass, a window, a partition, or blocking you cannot hit. A wall bumper is the cleaner choice when there is solid backing at lever height and you would rather not put a trip point on the floor. Floor stops also depend on the undercut: the FS434 works to 1-1/2 inches of gap, so a door hung high off carpet may need a wall stop or a taller floor stop instead.
5) Is the Ives FS434 handed, and does it matter which way the door swings?
Not handed. The FS434 is an angle stop that mounts to the floor and takes the door on its rubber face, so a left-hand or right-hand opening uses the same part. What decides the install is where you set it: mark it so the leaf lands on the rubber at the swing angle you want, clear of the traffic lane and clear of anything the door needs to reach, then drill. Same part number for every door in a building regardless of hand, which makes it easy to standardize a floor.
6) I need to order stops for a whole building. What exactly do I ask for to get this Ives one?
Ask for Ives FS434, steel angle floor stop, zinc plated. That is the model designation and it identifies the part on its own, with the fasteners for masonry and wood included in each one. Since the stop is not handed, one line item covers every door in the fleet, and the only thing to check door by door is that the undercut is 1-1/2 inches or less.
7) Will an Ives FS434 floor stop scuff or mark the bottom of my doors?
No. The contact face is soft, resilient black rubber, so it takes the hit rather than the door edge, and it keeps the leaf off the wall and the lever off the drywall behind it. The body under the rubber is steel with a zinc plated finish, which is what carries the load and resists corrosion on a slab.
8) How much floor space does the Ives FS434 take up, and will it be a trip hazard in a corridor?
It is a small footprint: H 2-5/8 in., W 1-1/2 in., L 2-3/4 in. That is compact enough to sit inside the door swing without eating walkway, but it is still a raised object on the floor. In corridors, egress paths, and healthcare or education spaces where carts and mobility devices run the wall line, set it as close to the wall as the swing allows, or use a wall bumper where there is backing behind the door.
How fast can I get the Ives FS4342C delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Ives FS4342C come with a warranty?
Absolutely. The Ives FS4342C is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Ives FS4342C?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the Ives FS4342C from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
