LCN Senior Swing Single Door A...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$6,802.35
LCN LCN 8310-3883 Senior Swing Single Door Package with 1 Safety Sensor, 1 Concealed Door Position Switch, and 1 Relay Module LCN-8310-3883

LCN Senior Swing Single Door Automation Package with Safety Sensor and Door Position Switch

(No reviews yet) Write a Review

Model: LCN-8310-3883

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6,802.35
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

LCN Senior Swing Single Door Automation Package with Safety Sensor and Door Position Switch

Complete Low Energy Convenience Door Automation Solution

The LCN Senior Swing Single Door Package provides a comprehensive touchless door automation solution designed for low energy convenience applications. This complete package includes one door-mounted safety sensor (8310-804-1), one concealed door position switch (8310-805C), and one programmable relay module (8310-845) specifically engineered for use with Senior Swing operators. The system enables pedestrians to activate doors with a simple hand wave, eliminating contact with actuators, door handles, or push bars for enhanced hygiene and accessibility.

Professional Features & Benefits

  • Complete Package Solution: Includes 8310-804-1 door mount safety sensor (approach side), 8310-805C concealed door position switch, and 8310-845 programmable relay module for comprehensive door automation.
  • Touchless Activation Technology: Motion-sensing technology detects hand waves to acknowledge intent to enter without requiring physical contact with door hardware.
  • Low Energy Convenience Operation: Designed specifically for Senior Swing operators to provide safe, controlled door movement with reduced force requirements.
  • Safety Sensor Integration: Door-mounted safety sensor provides approach-side detection to prevent door operation when obstructions are present.
  • Concealed Door Position Monitoring: Integrated door position switch provides discrete monitoring of door status for system feedback and control.
  • Programmable Relay Module: Dedicated relay module (8310-845) enables customizable control logic and integration with building automation systems.
  • Health and Well-Being Focus: Promotes hygiene by eliminating the need to touch door surfaces, actuators, or push bars in high-traffic environments.
  • Professional Installation: Engineered for commercial applications requiring reliable, code-compliant automatic door operation.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Installation & Operation

  1. Verify electrical requirements match available power supply and confirm compatibility with existing Senior Swing operator system.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the safety sensor (8310-804-1) on the door approach side ensuring adequate clearance for detection zone and wiring access.
  4. Install the concealed door position switch (8310-805C) in the specified location with proper alignment for door movement detection.
  5. Route and connect wiring according to manufacturer wiring diagrams for the relay module (8310-845) and sensor components. Use appropriate wire gauge and connectors for the application.
  6. Configure operational settings including detection zones, timing parameters, and relay functions per application requirements.
  7. Restore power and test all functions including touchless activation, safety sensor operation, door position monitoring, and integration with the Senior Swing operator system.
  8. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Healthcare Facility Automatic Doors
  • Commercial Building Accessibility Solutions
  • Educational Institution Entry Systems
  • Retail Store Convenience Access
  • Office Building Low Energy Operators
  • Multi-Tenant Residential Accessibility
  • Government Building ADA Compliance

Why Choose LCN Quality?

LCN Senior Swing automation packages deliver professional-grade reliability with integrated safety sensors and concealed monitoring components designed for demanding commercial applications. The complete package approach ensures compatibility between all system components while providing the touchless operation increasingly required in modern facilities. Engineered for dependable performance where automated door convenience and hygiene protection are essential.

Product Documentation & Resources

Product Specs

Series:
8310 Series
Application:
Used for monitored safety sensor kit for all Single Senior Swing door applications
Subcategory:
Closer Parts and Accessories
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Type:
Safety Packages
Commercial/Residential:
Commercial
Electronic:
Yes
ADA Compliant:
Yes
Parts and Accessories Type:
Installation Accessories
Product Attribute:
Parts and Accessories
Package:
Yes
Package Qnty:
3
Product Model:
8310-3883
Product Category:
Electronic Access Controls
Department:
Door Hardware
