LCN 8310 Series 36" x 6" Hardwired Touchless Actuator with Wheelchair Icon and Push to Open Text

Professional Touchless Access Control Solution

The LCN 8310 Series touchless actuator provides hands-free door activation with a 36" x 6" stainless steel activation surface. This hardwired low voltage unit features a blue handicap symbol that conforms with most accessibility codes and includes "PUSH TO OPEN" lettering for enhanced identification. Designed to meet California building codes, this actuator increases accessibility for wheelchair-bound entrants and can be easily mounted to any flat surface or bollard post with IP65 rated protection for electronic components.

Professional Features & Benefits

  • Large Activation Surface: 36" x 6" stainless steel touch plate provides ample activation area for enhanced accessibility and ADA compliance.
  • Touchless Operation: Motion sensing technology allows pedestrians to wave their hand in front of the wall plate without contact with actuator, door handle, or push bar for improved health and safety.
  • Accessibility Compliance: Blue handicap symbol conforms with most accessibility codes and meets California building codes for wheelchair accessibility.
  • Weather-Resistant Construction: IP65 rated protection for electronic components with stainless steel construction provides rugged performance for high-use commercial applications.
  • Clear Visual Identification: Includes "PUSH TO OPEN" lettering for enhanced user identification and proper operation guidance.
  • Versatile Mounting Options: Can be easily mounted to any flat surface or bollard post for flexible installation options including use with 8310 866 bollard post.
  • Hardwired Low Voltage: Reliable hardwired connection ensures consistent operation in commercial access control systems with momentary relay action.
  • Professional Design: Flush-mounted design is aesthetically pleasing and less susceptible to accidental damage in commercial environments.

Technical Specifications

  • ADA Compliant: Yes
  • Application: For use with 8310 866 bollard post
  • Battery Operated: No
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Display Text: Push To Open
  • Electronic: Yes
  • Mounting Method: Surface Mount
  • Parts and Accessories Type: Installation Accessories
  • Product Attribute: Parts and Accessories
  • Product Category: Electronic Access Controls
  • Product Color: Blue
  • Product Dimension: 36 x 6"
  • Product Group: Electronic Access Controls
  • Product Model: 8310-836T
  • Product Shape: Rectangle
  • Product Subgroup: Parts and Accessories
  • Product Substrate: Stainless Steel
  • Product Type: Door Actuators & Plates
  • Relay Action: Momentary (MOM)
  • Series: 8310 Series
  • Subcategory: Closer Parts and Accessories
  • Symbol: Handicap
  • Touchless Activation: No
  • Weather Resistant: Yes

Professional Applications

  • Commercial Building Security Systems
  • Healthcare Facility Access Control
  • Educational Institution Safety Systems
  • ADA Compliance Applications
  • Multi-Tenant Residential Properties
  • Retail Loss Prevention
  • Industrial Facility Monitoring

Why Choose LCN Quality?

LCN touchless actuators deliver professional-grade reliability with stainless steel construction designed for high-use commercial environments. The 8310 Series features flush-mounted design that is aesthetically pleasing and less susceptible to accidental damage, with IP65 rated protection for electronic components. Engineered for demanding commercial applications where dependable touchless access control and ADA compliance are essential.

Product Specs

Series:
8310 Series
Display Text:
Push To Open
Relay Action:
Momentary (MOM)
Symbol:
Handicap
Application:
For use with 8310 866 bollard post
Touchless Activation:
No
Subcategory:
Closer Parts and Accessories
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Type:
Door Actuators & Plates
Weather Resistant:
Yes
Commercial/Residential:
Commercial
Electronic:
Yes
Battery Operated:
No
ADA Compliant:
Yes
Parts and Accessories Type:
Installation Accessories
Product Attribute:
Parts and Accessories
Product Model:
8310-836T
Product Color:
Blue
Product Dimension:
36 x 6"
Mounting Method:
Surface Mount
Product Shape:
Rectangle
Product Category:
Electronic Access Controls
Product Substrate:
Stainless Steel
Department:
Door Hardware

LCN 8310-836T – Frequently Asked Questions

1) Does the LCN 8310-836T touchless actuator need batteries, or does it have to be wired?
It's a hardwired low voltage unit, not battery operated, so you need to pull low voltage wire to the mounting location before you set the plate. The relay action is momentary, meaning it sends a single open pulse to the operator each time it's triggered rather than holding the door open. Plan the rough-in wiring with the operator manufacturer's low voltage run, and set the plate location before the wall is closed up.
2) Can the LCN 8310 actuator be mounted outside on a post, or is it interior only?
Outdoors is fine. The stainless steel plate is weather resistant with IP65 rated protection for the electronics, and it surface mounts to any flat surface or to a bollard post. LCN's own post for it is the 8310 866 bollard, which is what you'd use for a parking lot or courtyard approach where there's no wall near the door.
3) How much wall space do I need for a 36 x 6 inch door actuator plate?
The plate measures 36 x 6 inches and is rectangular, so it wants a tall narrow run of clear flat surface. That footprint is why people pick it for a jamb return, a narrow pier between glass, or a bollard face, where a square 4-1/2 inch plate would look lost and a wide horizontal plate wouldn't fit at all. The long axis also means a wheelchair user can hit it at almost any height along the plate rather than having to find one small target.
4) Is the LCN 8310-836T actually touchless, or do you have to push it?
Wave activation. Motion sensing lets someone pass a hand in front of the plate with no contact on the actuator, the door handle, or the push bar. The plate still carries PUSH TO OPEN lettering and the blue wheelchair symbol, which is the standard marking people look for, so expect some users to touch it out of habit even though they don't need to.
5) Will this LCN actuator satisfy an accessibility inspection for a barrier free entrance?
The 8310-836T is ADA compliant and carries the blue handicap symbol that conforms with most accessibility codes, and it is built to meet California building codes. That covers the plate itself. The opening also needs a power operator behind it and the actuator placed within reach range of the approach, which is a layout call your drawings set, not a property of the plate.
6) What is a smaller-format alternative to the LCN 8310-836T when there is not room for a 36 by 6 inch plate beside the opening?
The LCN 8310-836T uses a 36 x 6 inch stainless steel plate, which needs a clear run of wall or a bollard face to land on. Where the available surface is a narrow jamb return or a mullion, the Camden CM-45 series is a 4-1/2 inch square push plate switch that occupies a fraction of that footprint. The trade is coverage area: the tall 36 inch LCN plate presents an activation band a wheelchair user can reach from a range of heights, while the 4-1/2 inch Camden square is a single fixed target that has to be mounted at the height the code official expects. For property managers standardizing entrances, decide the plate size per opening rather than per building.
7) The LCN 8310-836T is hardwired. What actuator can I use on an opening where I cannot pull low voltage wire?
The LCN 8310-836T is a hardwired low voltage unit with momentary relay action, so it assumes a wire path from the plate back to the operator. On a retrofit where fishing that wire means opening a finished wall or crossing a walkway, the Camden CM-45 series is offered wired or with a kinetic wireless transmitter, so the switch itself generates its signal on press and the run is eliminated. Contractors bidding an existing storefront or a masonry corridor should price both paths, since the wire route, not the plate, is usually the cost driver.
8) Is the Falcon 8310-819F a substitute for the LCN 8310-836T?
No. Both carry 8310 Series designations, which makes them easy to confuse on a purchase order, but they are different articles. The LCN 8310-836T is the actuator itself, a 36 x 6 inch stainless steel plate carrying the blue handicap symbol and PUSH TO OPEN lettering. The Falcon 8310-819F is a rugged plastic actuator mounting box measuring 1-1/2 by 4-3/4 inches for jamb and flush mount applications, meaning it is the enclosure a small actuator sits in rather than the activation device. Distributors filling an order against a 36 inch touch plate should confirm the model number 8310-836T, since the mounting box will not activate anything on its own.
9) What is the difference between the LCN 8310 touchless actuator and a Camden CM-45 push plate switch?
Two different activation methods. The LCN 8310-836T is a 36 x 6 inch hardwired touchless plate, activated by waving a hand in front of it. The Camden CM-45 Series is a 4-1/2 inch square push plate switch that the user presses, and it's offered wired or with a kinetic wireless transmitter, so it's the one to look at when you can't get low voltage wire to the actuator location. If contact-free operation is the point, as it usually is in healthcare, the LCN plate is the one that delivers it.
10) Do I need a mounting box for the LCN 8310 actuator, or does it mount flat to the wall?
It mounts flush and directly to any flat surface, which is part of why the design holds up: less of it sticks out to catch a cart or a door. Where you're mounting to a jamb or a surface you don't want to cut into, Falcon offers the 8310-819F rugged plastic actuator mounting box, 1-1/2 x 4-3/4 inches, for jamb and flush mount applications, though that box is sized for a small actuator rather than a 36 inch plate.
11) For an exterior entrance, how does the LCN 8310-836T compare with the Camden CM-45 on construction?
The LCN 8310-836T is a stainless steel plate rated weather resistant and specified for commercial use, which is why it is called out for surface mount on a flat wall or on a bollard post at an exterior approach. The Camden CM-45 series is a 4-1/2 inch square push plate switch; for openings where a fire rating is part of the assembly spec, note that the CM-45 carries no fire rating. Institutional buyers writing an exterior ADA entrance should match the material and exposure to the location first, then confirm the activation signal type with the operator supplier.
12) Is the LCN 8310-836T rated for a hospital or school entrance, or is it a residential product?
Commercial. The 8310-836T is a stainless steel, IP65 protected actuator built for high-use commercial openings, and the applications it's aimed at are healthcare access control, educational institutions, and multi-tenant residential properties. For a facility standardizing across many entrances, the same 36 x 6 inch plate with the wheelchair icon and PUSH TO OPEN text gives you one part number across the doors.
13) What LCN part number do I order for the tall touchless actuator with the wheelchair icon?
Model 8310-836T in the LCN 8310 Series, the 36 x 6 inch hardwired touchless actuator with the blue wheelchair symbol and PUSH TO OPEN lettering. There are no finish or size options to specify on it, so that single model number is the whole order for the plate.
How fast can I get the LCN 8310-836T delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the LCN 8310-836T come with a warranty?
Absolutely. The LCN 8310-836T is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the LCN 8310-836T?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the LCN 8310-836T from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
