Falcon MESC600DT Dummy Escutcheon Lever Trim for M9900 Series Exit Devices

Falcon MESC600DT Dummy Escutcheon Lever Trim for M9900 Series Exit Devices

Professional Exit Device Trim Solution

The Falcon MESC600DT Dummy Escutcheon provides professional exterior trim for M9900 Series rim and vertical rod exit devices. This Grade 1 ANSI-rated trim features a non-handed design with field reversible installation, accommodating doors up to 1-3/4" thick with 3-1/2" stile width requirements. UL listed with 3-hour fire rating, this escutcheon lever trim delivers reliable performance for commercial applications requiring ADA compliant access solutions.

Professional Features & Benefits

• Universal Compatibility: Designed specifically for M9900 Series rim and vertical rod exit devices with thru bolt mounting design.
• Dimensional Specifications: Fits doors up to 1-3/4" thick with 3-1/2" minimum stile width, overall dimensions of 10" length by 5" width.
• Fire-Rated Construction: UL listed with 3-hour fire rating for code-compliant installations in fire-rated openings.
• Non-Handed Design: Field reversible configuration eliminates handing concerns and simplifies inventory management.
• Grade 1 Performance: ANSI Grade 1 rating ensures heavy-duty performance suitable for high-traffic commercial applications.
• ADA Compliance: Meets ADA requirements for accessible door hardware in commercial installations.
• Complete Installation Kit: Includes all necessary mounting hardware for straightforward installation and retrofits.
• Medium Duty Rating: Engineered for reliable performance in demanding commercial environments up to 84" door height.

Technical Specifications

• Commercial/Residential: Commercial
• Department: Door Hardware
• Door Hand Direction: Field Reversible
• Electronic: No
• Fire Rating: Yes
• Handle Type: Lever
• Keyed Function: Non-Keyed
• Lock Function: Dummy
• Lock Type: Mortise
• Product Attribute: Mortise Locks
• Product Category: Mechanical Locks
• Product Function: Dummy
• Product Group: Mechanical Locks
• Product Model: MESC600DT
• Product Subgroup: Mortise Locks and Trim
• Product Type: Mortise Locks
• Subcategory: Mortise Locks

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness up to 1-3/4" and minimum 3-1/2" stile width compatibility.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for thru bolt installation.
3. Prepare door by drilling required holes as specified in manufacturer instructions for the thru bolt mounting system.
4. Install all mounting hardware and secure the escutcheon trim to door per manufacturer torque specifications using included hardware.
5. Adjust lever alignment for proper operation and verify smooth function throughout the full range of motion.
6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Falcon Quality?

Falcon MESC600DT escutcheon trim delivers professional-grade reliability with UL listed construction rated for 3-hour fire applications and ANSI Grade 1 performance standards. The field reversible design and included mounting hardware ensure dependable installation for demanding commercial applications where code compliance and accessible operation are essential.
