Philips Lighting 913701261901 CENTIUM ICN2P60N35I Electronic Fluorescent Ballast for F96T12 Lamps, 75W Instant Start

Philips Lighting 913701261901 CENTIUM ICN2P60N35I Electronic Fluorescent Ballast for F96T12 Lamps, 75W Instant Start

(No reviews yet) Write a Review

Model: 9.13701E+11
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$114.67
$50.06
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Philips Lighting CENTIUM ICN2P60N35I Electronic Fluorescent Ballast for F96T12 Lamps, 75W Instant Start

Philips Lighting's CENTIUM ICN2P60N35I is an electronic fluorescent ballast engineered for F96T12 lamps rated at 75W, wired in Parallel connection, with a universal 120-277V, 50-60Hz input drawing 0.48-1.13A. Featuring Instant Start ignition, a 0.99 power factor, 10% THD, and 1.6 crest factor, this CSA certified ballast is suitable for outdoor use in commercial fixture retrofits.

Key Features

  • Lamp Compatibility: Designed for F96T12 lamps rated 75W in Parallel connection configuration.
  • Universal Input: Operates on 120-277V, 50-60Hz, drawing 0.48-1.13A for flexible voltage applications.
  • Power Quality: 0.99 power factor, 10% THD, and 1.6 crest factor deliver efficient, low-distortion operation.
  • Durable Construction: Metal housing supports reliable performance in demanding environments.
  • Instant Start Ignition: 0.1 second nominal ignition time for immediate lamp start-up.
  • Wiring Flexibility: Supports Remote, Tandem, and Through wiring configurations up to 20' lamp distance.

Certifications & Compliance

  • CSA Certified
  • Suitable for Outdoor Use

Technical Specifications

  • Automatic Restart: Yes
  • Crest Factor (Nom): 1.6
  • Housing Type: N
  • Hum and Noise Level: A
  • Max Ballast Lamp Distance, Remote Wiring: 20'
  • Packs per Outer Box: 10
  • Quantity per Pack: 1
  • Remote Wiring Configuration Allowed: Yes
  • Suitable for Outdoor Use: Yes
  • Tandem Wiring Configuration Allowed: Yes
  • Through Wiring Configuration Allowed: Yes
  • Total Harmonic Distortion (USA): 10%
  • UL Recognized: No

Typical Applications

  • Commercial Fluorescent Lighting Retrofits
  • F96T12 Fixture Replacement Ballasts
  • Outdoor and Wet-Location Fixture Applications
  • Parallel-Wired Two-Lamp Fixtures

Why Philips Lighting?

Philips Lighting builds the CENTIUM ICN2P60N35I with a durable metal housing and CSA certification for dependable commercial and outdoor lighting performance. With Instant Start ignition, low total harmonic distortion, and flexible Remote, Tandem, and Through wiring configurations, this ballast delivers consistent, code-compliant operation for F96T12 fixture retrofits.

Manufacturer Resources

Product Specs

Approval Marks:
CSA certificate
Automatic Restart:
Yes
Ballast Factor Nom :
0.88
Ballast Type:
Electronic Fluorescent
Base Model:
ICN2P60N
Color Input Terminals:
No terminals
Color Output Terminals:
No terminals
Connector Type:
No connector
Crestfactor Nom :
1.6
Ean Upc Product:
7.81087E+11
Emc Immunity Standard:
FCC Non-Consumer
Housing Dimensions:
9.5" x 1.3" x 1.0"
Housing Material:
Metal
Housing Type:
N
Hum And Noise Level:
A
Ignition Method:
Instant Start
Ignition Time Nom :
0.1 s
Input Current Max :
1.13 A
Input Current Min :
0.48 A
Input Frequency:
50 to 60 Hz
Input Power Nom :
135-132 W
Input Voltage:
120 to 277 V
Lamp Connection:
Parallel
Lamp Type:
F96T12
Material Nr 12nc :
9.13701E+11
Max Ballast Lamp Distance Remote Wiring:
20'
Max Ballast Lamp Distance Tandem Wiring:
Any = 20'
Max Ballast Lamp Distance Through Wiring:
Any = 20'
Net Weight Piece :
350.000 g
Number Of Lamps:
1/2 piece/unit
Numerator Packs Per Outer Box:
10
Numerator Quantity Per Pack:
1
Order Code:
9.13701E+11
Order Product Name:
CENTIUM ICN2P60N35I
Power Factor Nom :
0.99
Rated Lamp Power:
75 W
Remote Wiring Configuration Allowed:
Yes
Suitable For Outdoor Use:
Yes
T Case Maximum Nom :
70 °C
Tandem Wiring Configuration Allowed:
Yes
Through Wiring Configuration Allowed:
Yes
Total Harmonic Distortion Usa:
10%
Ul Recognized:
No
Wire Gauge Nom :
18AWG mm
Wire Length By Color:
See data sheet
Wire Striplength:
0.50/0.375 mm
Wire Type:
Solid
Product Type:
Fluorescent Ballast
Department:
Electrical

Philips Lighting 9.13701E+11 – Frequently Asked Questions

1) What lamps does the Philips CENTIUM ICN2P60N35I ballast run?
It runs F96T12 lamps rated at 75 W each, one or two lamps per ballast. Lamps are wired in parallel, so if one lamp fails the other keeps burning. If your fixture has 8-foot T8 or T12HO lamps instead, this is not the right ballast.
2) Will this Philips CENTIUM 8-foot ballast work on 120V and 277V?
Yes. The ICN2P60N35I is a universal-voltage ballast, 120 to 277 V at 50 to 60 Hz, so the same part covers 120 V residential/light commercial panels and 277 V commercial lighting circuits. Input current runs 0.48 A minimum to 1.13 A maximum depending on voltage and lamp count, and nominal input power is 132-135 W on a two-lamp load.
3) Will this ballast fit inside my existing 8-foot strip fixture channel?
The metal housing measures 9.5 x 1.3 x 1.0 inches, which is the standard small-can electronic ballast footprint that drops into most 8-foot strip and industrial channels. It ships with no input or output terminals and no connector, so it is a flying-lead ballast: 18 AWG solid wire that you splice with wire nuts. Piece weight is 350 g.
4) How far can the ballast be from the lamps if I remote-mount it?
Remote mounting is allowed up to 20 feet between ballast and lamp. Tandem and through-wiring configurations are both permitted as well, each with the same 20-foot limit on any lead. That lets one ballast feed lamps in an adjacent fixture in a row of channels.
5) Can I use this Philips ballast in an outdoor or unheated sign and canopy fixture?
It is rated suitable for outdoor use, and it restarts automatically after a lamp is replaced or power is cycled. Keep the case at or below 70 C max at the case temperature point, which is what governs whether it survives a tight enclosure or a hot canopy.
6) Is this an instant start or rapid start ballast, and does that matter for my application?
Instant start, with a nominal 0.1 second ignition time. Instant start draws the least input power and is the usual choice for spaces where lights run long hours and are not switched frequently. In a space on occupancy sensors that cycles the lights many times a day, a programmed or rapid start ballast gives longer lamp life.
7) Is the power quality good enough for a commercial building with harmonic limits?
Power factor is 0.99 nominal and total harmonic distortion is 10 percent, which meets the under-20-percent THD threshold commonly specified for commercial and institutional lighting. Crest factor is 1.6, and the sound rating is Class A, the quietest grade, so it is suitable for offices, classrooms, and libraries.
8) What approvals does this Philips electronic fluorescent ballast carry?
It holds a CSA certificate and meets the FCC Non-Consumer EMC immunity standard, which is the commercial/industrial FCC class rather than the tighter residential one. That EMC class is worth noting if the fixtures go into a residential building where radio interference is a concern.
9) How does the CENTIUM ICN2P60N35I ship, and how many come in a case?
Each pack holds one ballast, and an outer box holds 10 packs, so a full case is 10 ballasts. Order code and product name on the box read CENTIUM ICN2P60N35I under Philips material number 913701261901. Useful if you are standardizing a warehouse or parking structure relamp and buying by the case.
10) What wire strip length should I use when splicing this ballast in?
Strip the 18 AWG solid leads to the 0.50/0.375 mm specification given for the ballast. Because it comes with no input or output terminals, every connection is a field splice, so plan on wire nuts or push-in connectors for both the line side and each lamp lead.
