Sargent Signature 10-34 6-Pin Rim Cylinder with Protected Key Control

Sargent Signature 10-34 6-Pin Rim Cylinder with Protected Key Control Technology

Advanced Security Cylinder with Exclusive Key Control Technology

The Sargent Signature 10-34 delivers enhanced security through its protected key design and unique 6-pin cylinder construction with dual blocking bars. This rim-type cylinder features a 27/32" (21mm) screw pattern specifically designed for through-bolted Sargent exit devices, providing superior resistance to manipulation attempts and unauthorized key duplication. The solid brass construction ensures long-term durability in demanding commercial applications.

Professional Features & Benefits

• Precision Mounting Pattern: 27/32" (21mm) screw pattern ensures proper fit with through-bolted Sargent exit devices for secure installation.
• Advanced 6-Pin Design: Features 2 blocking bars with shear lines working with 6 factory-loaded side pins for superior manipulation resistance.
• Heavy-Duty Construction: Solid brass cylinder with brass, bronze, or stainless steel cap options for exceptional durability in commercial applications.
• Protected Key Control System: Exclusive end-user pattern with dimpled key design prevents unauthorized key duplication and provides enhanced security control.
• Universal System Compatibility: Signature keys operate both Signature and non-Signature cylinders, while non-Signature keys cannot access Signature cylinders for flexible key management.
• Complete Assembly Options: Available as complete 6-pin assembly (10-34), plug assembly (13-3845), or shell & slide assembly (13-3847) for various installation needs.
• Professional Installation Hardware: Furnished standard with break-off screws and back plate for secure mounting and professional installation.
• Extensive Finish Options: Multiple cylinder finishes available including 3, 4, 9, 10, 10B, 10BE, 10BL, 15, 20D, 32, 32D, BSP, WSP with plug finishes in 4, 15, BSP for architectural coordination.

Technical Specifications

• Refer to manufacturer documentation for complete technical specifications.

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Sargent Quality?

Sargent Signature cylinders deliver professional-grade security with solid brass construction and protected key control technology that resists manipulation attempts. The unique 6-pin design with blocking bars provides enhanced security while maintaining compatibility with existing key systems. Engineered for demanding commercial applications where superior key control and reliable performance are essential.

Product Documentation & Resources

• [Catalog] SARGENT Full Line Catalog
