Schlage Residential FC21 Dawes Glass Knob x Broadway Lever Passage and Privacy Cylindrical Lock

Schlage Residential FC21 Dawes Glass Knob x Broadway Lever Passage/Privacy Cylindrical Lock

Dual-Function Residential Lock with Designer Glass Knob and Lever Combination

The Schlage Residential FC21 combines the elegant Dawes glass knob with the Broadway lever design in a versatile passage/privacy lock configuration. This Grade 2 cylindrical lock fits doors from 1-3/8" to 1-3/4" thick with dual backset options for 2-3/8" or 2-3/4" installations. The lock features passage function as default with privacy conversion capability via interior pushbutton, and includes a 1" x 2-1/4" latch with 1/2" throw for reliable operation.

Professional Features & Benefits

• Dual-Function Operation: Passage function as default with privacy pushbutton conversion on interior side for versatile room applications.
• Emergency Access: Privacy function can be opened from outside using small emergency unlock tool for safety and convenience.
• Universal Door Compatibility: Fits door thickness range of 1-3/8" to 1-3/4" with dual backset latches for 2-3/8" or 2-3/4" installations.
• Designer Hardware Combination: Features elegant Dawes glass knob paired with Broadway lever design for distinctive residential styling.
• Grade 2 Certification: ANSI/BHMA A156.2-2017 Grade 2 and A156.39-2015 Residential Grade AA certified for reliable performance.
• Easy Installation: Simple 3-step installation process requiring only a screwdriver for quick setup.
• Fire Door Compatible: Available UL Listed for 90 minute fire door applications where required.
• 10 Year Warranty: Comprehensive manufacturer warranty provides long-term protection and confidence.

Standard Features

Certification:ANSI/BHMA A156.2-2017 Grade 2
ANSI/BHMA A156.39-2015 Residential Grade AAA
Available UL Listed for 90 minute fire door
Latch: 1"x 2-1/4", 1/4" radius corner faceplate, 1" housing diameter, 1/2" throw, circular drive-in included, universal latch
Strike: 1-5/8" x 2-1/4" radius corner, full lip
Backset: Dual backset latches, fits either 2-3/8" or 2-3/4" backsets
Cylinder: 5-Pin, C keyway, keyed alike (KA4)
Door Range: 1-3/8" – 1-3/4"
Keys: Two per lock, 5-pin, C section

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness between 1-3/8" and 1-3/4" and backset measurement of either 2-3/8" or 2-3/4".
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for the cylindrical lock installation.
3. Prepare door by drilling required holes per manufacturer specifications, ensuring proper alignment for both knob and lever sides.
4. Install the dual backset latch mechanism and secure the lock components to door per manufacturer torque specifications.
5. Adjust operational components for proper alignment and test both passage and privacy functions including emergency unlock capability.
6. Test device operation to verify proper function of both knob and lever operation and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Residential Interior Doors
• Bedroom and Bathroom Privacy Applications
• Home Office and Study Rooms
• Guest Room and Secondary Bedroom Doors
• Closet and Storage Room Access
• Multi-Family Residential Properties
• Assisted Living and Senior Housing

Why Choose Schlage Residential Quality?

Schlage Residential FC21 locks deliver professional-grade reliability with stainless steel construction and Grade 2 ANSI/BHMA certification for demanding residential applications. The 10 Year manufacturer warranty provides comprehensive protection and confidence in long-term performance. Engineered for easy installation and dependable daily operation with the distinctive combination of glass knob and lever design elements.
