Schlage Residential B62 Grade 1 Double Cylinder Deadbolt with Steel Strike Reinforcer

Schlage Residential B62 Grade 1 Double Cylinder Deadbolt with Steel Strike Reinforcer

Professional-Grade Security for Residential Applications

The Schlage Residential B62 Grade 1 Double Cylinder Deadbolt delivers commercial-grade security for residential exterior doors with ANSI/BHMA Grade 1 certification and Grade AAA residential rating. This double cylinder deadbolt features a 1" throw with 25mm extension, adjustable 2-3/8" or 2-3/4" backset, and fits door thickness from 1-3/8" to 1-3/4". The integrated steel strike reinforcer with 3" screws provides enhanced kick-in protection by penetrating through the door jamb into the wall stud.

Professional Features & Benefits

• Grade 1 Commercial Certification: ANSI/BHMA A156.36-2016 Commercial Grade 1 and A156.40-2015 Residential Grade AAA for superior security performance.
• Enhanced Kick-In Protection: Patented steel strike reinforcer with 3" heavy gauge screws penetrates through door jamb into wall stud for maximum security.
• Full 1" Throw Deadbolt: 25mm throw extension with hardened steel roller prevents cutting and sawing attacks.
• Adjustable Backset: Dual option latch accommodates 2-3/8" or 2-3/4" backset for versatile installation requirements.
• Double Cylinder Security: Requires key operation from both interior and exterior sides for maximum security control.
• Heavy-Duty Construction: 1" housing diameter with radius corner design and reinforced strike plate for commercial-grade durability.
• Fire Door Compatible: Available UL Listed for 3-hour fire door applications when specified.
• Manufacturer Warranty: 10 Year warranty coverage plus lifetime finish and lifetime mechanical warranties for residential applications.

Standard Features

Certification: ANSI/BHMA A156.36-2016 Commercial Grade 1;
ANSI/BHMA A156.40-2015 Residential Grade AAA;
Available UL Listed for 3-hour fire door (B60, B80 and B81 only).
Deadbolt: 1" x 2-1/4", radius corner, 1" housing diameter, 1" throw, latch number 12-321
Strike: 1-1/8" x 2-3/4", 1/4" radius corner, strike number 10-116
Backset: Adjustable for 2-3/8" or 2-3/4"
Cylinder Standard: N: 5-pin, keyed 5-pin, C keyway, keyed alike (KA4)
Optional N6: 5-pin, keyed 5-pin, C keyway, keyed alike (KA4)
Optional N6-5: 6-pin, keyed 5-Pin, C keyway, keyed alike (KA4)
Door Range: Standard 1-3/8" – 1-3/4", Optional door thickness available up to 2-1/4" for B60.
Keys: Two keys per lock, 5-pin, keyed 5-pin, C section
Reinforcement: Integrated strike and reinforcer with 3" screws

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness between 1-3/8" and 1-3/4", and determine appropriate backset (2-3/8" or 2-3/4").
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces for the deadbolt housing and strike plate.
3. Prepare door by drilling the required 2-1/8" hole for the deadbolt housing and 1" hole for the cylinder, plus routing for the latch mechanism.
4. Install the integrated strike reinforcer and strike plate using the provided 3" screws, ensuring proper penetration through the door jamb into the wall stud.
5. Mount the deadbolt assembly and adjust the dual option latch for the selected backset (2-3/8" or 2-3/4") ensuring proper alignment with the strike.
6. Test deadbolt operation from both sides with the provided keys to verify smooth 1" throw extension and retraction. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Residential Exterior Door Security
• Multi-Family Housing Units
• Condominium and Townhome Complexes
• Rental Property Security Upgrades
• Home Security System Integration
• Fire Door Applications (when UL Listed)
• High-Security Residential Requirements

Why Choose Schlage Residential Quality?

Schlage Residential B62 deadbolts deliver professional-grade security with Grade 1 commercial certification and patented steel strike reinforcer construction rated for demanding residential applications. The 10 Year warranty plus lifetime finish and lifetime mechanical warranties provide added confidence and long-term protection. Engineered for superior kick-in resistance and cutting protection where dependable home security is essential.

ANSI/BHMA Grade 1 rated — the highest residential security classification. Hardened steel bolt with anti-pick, anti-bump, and anti-saw cylinder. Support Resources: Manuals Hub: Schlage Manuals, Installation Guides & Templates (https://www.schlage.com/en/home/support/installation-manuals-templates.html) || Installation Guides: B60/B62 Deadbolt Installation Instructions (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/b60-b62-schlage-deadbolt-installation-instructions.pdf) | B60/B62 Deadbolt Installation Instructions (alt) (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/P515-788.pdf) | Rekeying Quick Start Guide (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/P513-325.pdf) || FAQs & Support: Schlage Product FAQs (https://www.schlage.com/en/home/support/faqs.html)
