Schlage Residential FB50 Flair Single Cylinder Keyed Entry Lever Set and Deadbolt Combo

Schlage Residential FB50 Flair Single Cylinder Keyed Entry Lever Set and Deadbolt Combo

Complete Entry Security Solution with Professional-Grade Performance

The Schlage Residential FB50 Flair combines a keyed entry lever set with deadbolt in one complete combo pack, designed for residential front entry applications. This single cylinder system locks and unlocks from the exterior using a key in the deadbolt and features interior thumbturn operation. Built for doors with 1-3/8" to 1-3/4" thickness, the FB50 exceeds BHMA Grade 1 criteria for the deadbolt and Grade 2 for the handle, ensuring reliable performance with durable zinc and steel construction.

Professional Features & Benefits

• Door Thickness Compatibility: Designed for 1-3/8" to 1-3/4" door thickness with adjustable 2-3/8" or 2-3/4" backset for versatile installation options.
• Dual-Grade Performance: Exceeds BHMA Grade 1 criteria for deadbolt and Grade 2 for handle, providing superior security and durability standards.
• Complete Combo Solution: Single cylinder keyed entry system includes both lever set and deadbolt for comprehensive front entry security in one package.
• Durable Construction: Zinc and steel substrate materials ensure lasting performance and resistance to wear in residential applications.
• Easy Installation: Simple 3-step installation process requires only a screwdriver, with all mounting hardware included for quick setup.
• Reversible Operation: Non-handed design allows installation on left or right swing doors without additional components.
• Manufacturer Warranty: 10 Year limited lifetime mechanical and finish warranty for added confidence and protection.
• Professional Hardware Specifications: Includes 5 Pin Schlage C cylinder, dual option dead latch, and full lip radius strike for complete installation.

Standard Features

Schlage's F Series designs range from bold to classic to match any residential décor.  Plus, it features an easy 3-step installation, only a screwdriver needed.

Combo Pack: Single cylinder keyed entry door hardware is locked and unlocked from the exterior using a key in the deadbolt and can be locked and unlocked from the interior using the thumbturn.

This entry set would be ideal for the front entry of a home.

• Exceeds criteria for BHMA Grade 1 for the deadbolt and Grade 2 for the handle
• Durable construction ensuring lasting use
• Simply installs on doors with 1-3/8" to 1-3/4" thickness
• Mounting hardware is included
• Covered under a limited lifetime mechanical and finish warranty

Specifications:

• Backset: Adjustable 2-3/8" or 2-3/4"
• Cross Bore: 1-1/2", 2-1/8"
• Edge Bore: 1", 7/8"
• Door Thickness: 1-3/8" to 1-3/4"
• Handing: Reversible Left or Right
• Handle Width: 2-1/8"
• Handle Height: 2-1/8"
• Handle Projection: 2-5/16"
• Product Weight: 3 lbs.
• Latch Faceplate: Round Corner, Square Corner or Drive-In
• Cylinder: 5 Pin Schlage C

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness between 1-3/8" to 1-3/4", backset adjustment for 2-3/8" or 2-3/4", and cross bore dimensions.
2. Use manufacturer-provided templates to mark mounting hole locations accurately including 1-1/2" and 2-1/8" cross bore and 1" or 7/8" edge bore requirements.
3. Prepare door by drilling required holes per specifications, ensuring proper alignment for both lever set and deadbolt components.
4. Install mounting hardware and secure both lever set and deadbolt assemblies to door per manufacturer torque specifications using included hardware.
5. Adjust operational components including thumbturn and key cylinder for proper alignment, smooth operation, and secure latching throughout full range of motion.
6. Test both lever and deadbolt operation to verify proper function, key operation, and interior thumbturn engagement. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Residential Front Entry Doors
• Single Family Home Security
• Townhouse and Condominium Entrances
• Apartment Unit Entry Points
• Home Office and Study Entrances
• Multi-Family Residential Properties
• Residential Renovation Projects

Why Choose Schlage Residential Quality?

Schlage Residential FB50 Flair lever sets deliver professional-grade reliability with zinc and steel construction that exceeds BHMA Grade 1 criteria for deadbolts and Grade 2 for handles. The 10 Year limited lifetime mechanical and finish warranty provides long-term protection and confidence. Engineered for demanding residential applications where dependable security and smooth operation are essential for daily use.
