Schlage Residential FE285 Camelot Lower Handleset with Georgian Knob Non-Keyed Entry

Schlage Residential FE285 Camelot Lower Handleset with Georgian Knob Non-Keyed Entry

Professional Residential Entry Hardware Solution

The Schlage Residential FE285 Camelot handleset features the classic Georgian knob design for residential entrance applications. This non-keyed lower handleset is designed for doors ranging from 1-3/8" to 1-3/4" thickness and combines with electronic deadbolts for complete front entry sets. Built with zinc and steel construction and certified to ANSI/BHMA Grade 2 standards, this handleset delivers reliable performance with easy 3-step installation requiring only a screwdriver.

Professional Features & Benefits

• Door Thickness Compatibility: Accommodates 1-3/8" to 1-3/4" doors with dual backset latches fitting either 2-3/8" or 2-3/4" backsets for versatile installation options.
• Grade 2 Certification: ANSI/BHMA A156.2-2017 Commercial Grade 2 and ANSI/BHMA A156.39-2015 Residential Grade AAA certification ensures professional-grade reliability and performance.
• Durable Construction: Zinc and steel substrate materials provide long-lasting durability for demanding residential entrance applications.
• Universal Installation: Non-handed design with dual backset latches and universal latch configuration simplifies installation across various door preparations.
• Complete Entry System: Designed to combine with electronic deadbolts for comprehensive front entry security with latch retraction by thumbpiece from outside or inside knob operation.
• Fire Door Compatibility: Available UL Listed for 3-hour fire door applications (F10, F40 CSV Only, F51A, F80 functions) for enhanced safety compliance.
• Easy Installation: Simple 3-step installation process requires only a screwdriver, reducing installation time and complexity.

Standard Features

Certification: ANSI/BHMA A156.2-2017 Commercial Grade 2; ANSI/BHMA A156.39-2015 Residential Grade AAA; Available UL Listed for 3-hour fire door (F10, F40 (CSV Only), F51A, F80 functions).
Latch: 1"x 2-1/4", 1/4" radius corner faceplate, 7/8" housing diameter, 1/2" throw, circular drive-in included, universal latch
Strike: 1-5/8" x 2-1/4" radius corner, full lip, no box
Backset: Dual backset latches, fits either 2-3/8" or 2-3/4" backsets
Cylinder: 5-Pin, C keyway, keyed alike (KA4)
Door Range: 1-3/8" – 1-3/4"
Keys: Two per lock, 5-pin, C section

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness between 1-3/8" and 1-3/4", and determine appropriate backset (2-3/8" or 2-3/4").
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for the handleset and latch assembly.
3. Prepare door by drilling required holes for the latch, thumbpiece, and interior knob components as specified in manufacturer instructions.
4. Install the dual backset latch (16-080 spring latch) and strike plate (10-027 full lip radius strike) ensuring proper alignment and secure mounting.
5. Mount the exterior thumbpiece and interior Georgian knob components, securing all hardware per manufacturer torque specifications.
6. Test handleset operation to verify proper latch retraction from both thumbpiece and interior knob, and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Residential Front Entry Doors
• Single-Family Home Entrance Systems
• Townhouse and Condominium Entry Points
• Multi-Family Residential Properties
• Apartment Building Unit Entrances
• Residential Security Upgrade Projects
• New Construction Residential Developments

Why Choose Schlage Residential Quality?

Schlage Residential FE285 handlesets deliver professional-grade reliability with zinc and steel construction certified to ANSI/BHMA Grade 2 standards for demanding residential applications. The F Series design combines classic styling with modern functionality, featuring easy 3-step installation and universal compatibility. Engineered for dependable performance where residential entrance security and aesthetic appeal are essential.
