Schlage Residential FE595 Camelot Keypad Entry Electronic Lock with Georgian Interior Knob

Schlage Residential FE595 Camelot Keypad Entry Electronic Lock with Georgian Interior Knob

Convenient Keypad Security for Residential Applications

The Schlage Residential FE595 Camelot keypad entry lock delivers convenient electronic security with traditional lock reliability. This Grade 2 electronic lock features a 5-pin C keyway cylinder, adjustable 2-3/8" to 2-3/4" backset, and accommodates door thickness from 1-3/8" to 1-3/4". The lock operates on a single 9V battery and stores up to 19 access codes with 2 pre-set unique 4-digit codes included.

Professional Features & Benefits

• Door Compatibility: Fits door thickness from 1-3/8" to 1-3/4" with adjustable 2-3/8" to 2-3/4" backset for versatile installation options.
• Keypad Access Control: Store up to 19 access codes with 2 pre-set unique 4-digit codes for flexible user management.
• Battery Operation: Single 9V battery power with wide operating temperature range from -35C to 66C exterior and -10C to 50C interior.
• Grade 2 Construction: ANSI/BHMA F76 rated with 5-pin C keyway conventional cylinder for reliable security performance.
• Flexible Locking Options: Auto lock and flex lock features with push-button locking function and inside knob/lever release.
• Complete Hardware Package: Includes 1/2" throw latch with 7/8" housing diameter, 1" x 2-1/4" radius corner faceplate, and full lip radius strike.
• Manufacturer Warranty: 3 Year warranty coverage for added confidence and protection.

Standard Features

Product Dimensions: 3" x 6.5" x 6.5"
Battery: 9V battery (1)
Latch Throw: 1/2" throw, 7/8" housing diameter
Cylinder: 5-pin, C keyway
Door Thickness: 1-3/8" to 1-3/4"
Cross Bore: 2-1/8"
Latch Faceplate Size: 1" x 2-1/4" radius corner
Latch/Backset: 2-3/8" to 2-3/4" adjustable
Latch Faceplate Size: 1" x 2-1/4"
Latch Faceplate Options: Spring latch radius corner and circular drive-in faceplates
Strike: 1-5/8" x 2-1/4", radius corner, full lip latch strikes
Keys: 1 Key
Codes: 2 pre-set unique 4-digit access codes, storage of up to 19 access codes
Operating Temperatures: Outside lock body (exterior mounted): -35C to 66C Inside lock body (interior mounted): -10C to 50C

Installation & Operation

1. Verify electrical requirements and confirm 9V battery compatibility before proceeding with installation.
2. Disconnect any existing lock hardware and prepare door with 2-1/8" cross bore hole for lock installation.
3. Mount the exterior keypad unit and interior knob assembly ensuring proper alignment and secure attachment to door.
4. Install the 9V battery and configure initial access codes according to manufacturer programming instructions.
5. Configure operational settings including auto lock and flex lock features per application requirements.
6. Test all functions including keypad entry, manual key operation, interior knob release, and battery status indicators.
7. Complete final inspection and document access codes. Refer to manufacturer documentation for complete installation instructions and programming procedures.

Professional Applications

• Single Family Residential Homes
• Townhomes and Condominiums
• Rental Property Management
• Home Office and Study Areas
• Guest House and Secondary Entrances
• Residential Security Upgrades
• Multi-Generational Housing

Manufacturer Resources

• Installation Instructions
• User's Guide

Why Choose Schlage Residential Quality?

Schlage Residential FE595 electronic locks deliver proven residential security with Grade 2 ANSI/BHMA F76 rating and reliable 5-pin conventional cylinder construction. The 3 Year manufacturer warranty provides added confidence for long-term residential use. Engineered with nearly a century of Schlage dedication to security, quality and innovation for dependable home protection.

Keypad lever with Flex Lock technology — set to always-locked or passage mode as needed. Supports up to 19 programmable access codes. Support Resources: Manuals Hub: Schlage Manuals, Installation Guides & Templates (https://www.schlage.com/en/home/support/installation-manuals-templates.html) || Installation Guides: FE575/FE595 Keypad Lever Installation Instructions (current) (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/fe595-keypad-lock-installation-instructions.pdf) | FE575 Keypad Lever Installation Instructions (alt) (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/fe575-keypad-lock-installation-instructions.pdf) | FE575/FE595 Installation and Programming Guide (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/P515-859.pdf) || Door Prep Templates: FE595 Door Prep Template — No Existing Holes (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/1105-b.pdf) | FE595 Door Prep Template — Existing Holes (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/1105.pdf) || User Guides & Manuals: Keypad Locks User Guide (BE365/FE575/FE595) (https://www.schlage.com/content/dam/sch-us/documents/pdf/installation-manuals/23780042.pdf) || Programming Guide: Schlage Programming Guides (https://www.schlage.com/en/home/support/programming-guides.html) || FAQs & Support: Schlage Keypad Flex Lock Lever FAQs and Support (https://www.schlage.com/en/home/support/faqs/keypad.html) | Schlage Product FAQs (https://www.schlage.com/en/home/support/faqs.html)
