Schlage Residential JE285 Barcelona Style Handleset with Seville Lever - Non-Keyed Entry Function

Schlage Residential JE285 Barcelona Style Handleset with Seville Lever - Non-Keyed Entry Function

Professional Residential Entry Hardware Solution

The Schlage Residential JE285 Barcelona Style Handleset combines classic design with reliable mechanical operation for residential entrance applications. This non-keyed handleset features the elegant Barcelona upper trim paired with a Seville lever handle, designed for doors ranging from 1-3/8" to 1-3/4" thickness. The dual backset latch accommodates both 2-3/8" and 2-3/4" installations, while the Grade 2 certification ensures commercial-grade durability for demanding residential use.

Professional Features & Benefits

• Door Compatibility: Fits door thickness range of 1-3/8" to 1-3/4" with dual backset options for 2-3/8" or 2-3/4" installations.
• Grade 2 Certification: ANSI/BHMA A156.2-2017 Commercial Grade 2 and ANSI/BHMA A156.39-2015 Residential Grade AAA for superior durability and performance.
• Fire Door Compatible: Available UL Listed for 3-hour fire door applications with specific functions (F10, F40 CSV Only, F51A, F80).
• Easy Installation: Simple 3-step installation process requiring only a screwdriver for quick professional setup.
• Universal Latch System: 1" x 2-1/4" latch with 1/4" radius corner faceplate, 7/8" housing diameter, and 1/2" throw for reliable latching.
• Complete Strike Package: Includes 1-5/8" x 2-1/4" radius corner full lip strike for secure door frame integration.
• Durable Construction: Zinc and steel substrate materials provide long-lasting performance in residential applications.
• Flexible Entry Function: Latch retracted by thumbpiece from outside or by inside knob/lever, designed to combine with electronic deadbolt for complete front entry set.

Standard Features

Certification: ANSI/BHMA A156.2-2017 Commercial Grade 2; ANSI/BHMA A156.39-2015 Residential Grade AAA; Available UL Listed for 3-hour fire door (F10, F40 (CSV Only), F51A, F80 functions).
Latch: 1"x 2-1/4", 1/4" radius corner faceplate, 7/8" housing diameter, 1/2" throw, circular drive-in included, universal latch
Strike: 1-5/8" x 2-1/4" radius corner, full lip, no box
Backset: Dual backset latches, fits either 2-3/8" or 2-3/4" backsets
Cylinder: 5-Pin, C keyway, keyed alike (KA4)
Door Range: 1-3/8" – 1-3/4"
Keys: Two per lock, 5-pin, C section

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness between 1-3/8" and 1-3/4", and determine appropriate backset (2-3/8" or 2-3/4").
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces for both upper Barcelona trim and lower Seville lever components.
3. Prepare door by drilling required holes and routing as specified in manufacturer instructions for the dual backset latch system.
4. Install the spring latch (16-080) and strike plate (10-027) components, ensuring proper alignment with door frame preparation.
5. Mount the Barcelona upper trim and Seville lever assembly, securing all mounting hardware per manufacturer torque specifications.
6. Test handleset operation to verify proper thumbpiece and lever function, smooth latching action, and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Residential Front Entry Doors
• Single-Family Home Entrance Systems
• Townhouse and Condominium Entry Points
• Multi-Family Residential Properties
• Custom Home Construction Projects
• Residential Door Replacement and Upgrade Projects
• Property Management Maintenance Programs

Why Choose Schlage Residential Quality?

Schlage Residential JE285 handlesets deliver professional-grade reliability with zinc and steel construction rated to both Commercial Grade 2 and Residential Grade AAA standards. The J Series design range offers versatile styling options from bold to classic to match any residential décor, while the simple 3-step installation process ensures professional results. Engineered for demanding residential applications where dependable entrance hardware performance and attractive design are essential.
