ASC Engineered Solutions 11/2X1 GALV MI 90 ELL

Both openings are female pipe thread (FPT), cut to ASME B1.20.1, which is standard NPT taper thread. So it threads onto male-threaded pipe nipples or MIP fittings on both sides. There is no socket or press end here, it is a straight female-to-female threaded reducing elbow.

It reduces. One end takes 1-1/2 inch pipe, the other takes 1 inch, so it turns the corner and steps the line down in a single fitting instead of needing an elbow plus a bushing. If you need both ends the same, you want a straight 1-1/2 x 1-1/2 or 1 x 1 elbow instead.

It carries UL/FM approval, so it is acceptable for fire protection piping where UL Listed / FM Approved threaded fittings are called for. It is standard (STD) pattern malleable iron with pressure ratings per ASME B16.3. Confirm the required working pressure for your system against the B16.3 rating for the size.

The casting is malleable iron to ASTM A-197, and the fitting is dimensioned to ASME B16.3. That means it interchanges with any other B16.3 Class 150 threaded malleable iron elbow of the same size, so take-out length and thread engagement match what your drawing or existing run already uses.

This is a galvanized malleable iron threaded elbow intended for general plumbing and mechanical piping. Galvanized malleable iron is commonly run on air, water and fire protection lines. For potable service, check your local code and any lead-free requirement for the jurisdiction before installing, since that is governed by the AHJ rather than the fitting dimensions.

The manufacturer part number is 311009807 from ASC Engineered Solutions. Give that number when matching to a submittal or reordering to keep the same B16.3 galvanized malleable iron reducing ell across the job.

1.06 lbs each. Useful if you are pricing out a hanger layout or a bulk order, since a run with a lot of reducing ells adds up quickly on unsupported spans.
