15503 Viega ProPress tee Smart Connect technology Copper, 2'' x 1-1/2'' x 1-1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Material Type:
- Copper
- Product Dimension:
- 2'' x 1-1/2'' x 1-1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 2.594"
- Product Height:
- 4.079"
- Product Weight:
- 1.386 lbs
- Product Width:
- 5.787"
- Product Material:
- Copper
Viega 15503 – Frequently Asked Questions
1) What size pipe does the Viega ProPress 15503 tee connect?
The 15503 is a reducing tee sized 2 inch by 1-1/2 inch by 1-1/2 inch. The run is 2 inch on one end and 1-1/2 inch on the other, with a 1-1/2 inch branch. All three ends are press connections for copper tube, so nothing threads or solders.
2) Can I use the Viega 15503 ProPress tee on anything other than copper tube?
No. The 15503 is a copper ProPress fitting, made to press onto copper tube in those sizes. For PEX, steel, or stainless runs you need the fitting line built for that material, not this one.
3) I need to branch a 1-1/2 inch line off a 2 inch main without hot work. Is this the right fitting?
Yes, that is exactly the configuration. The 15503 reduces a 2 inch copper run to 1-1/2 inch and takes a 1-1/2 inch branch off it, all by press. No torch, so it works in occupied buildings and anywhere a hot work permit would otherwise be required.
4) Does the Viega 15503 tee have Smart Connect, and what does that actually do on the job?
It does. Smart Connect leaves a deliberate leak path in the unpressed fitting, so when you pressure test the system any connection you skipped weeps and shows itself before the walls close up. Press the joint and the feature seals. It is a find-your-misses tool, not a substitute for pressing every connection.
5) What part number do I order for a 2 x 1-1/2 x 1-1/2 ProPress copper tee?
Viega part number 15503. That is the manufacturer number to quote, and it covers the copper press tee in the 2 x 1-1/2 x 1-1/2 configuration.
6) Where is the Viega 15503 press tee manufactured?
Germany. That matters on public and institutional jobs where country of origin has to be documented in the submittal package.
