2 AL TP COMP LUG 1HL 1/4IN PNK
Manufacturer Resources
Product Specs
- Cable Size:
- 2 AWG
- Country Of Origin:
- Mexico (MX)
- Product Group:
- Wire Termination
- Product Type:
- Aluminum One-Hole Lug
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Stud Size:
- 1/4 in
- Sub Brand Label:
- Blackburn
- Type2:
- Cable or wire lug
- Department:
- Electrical
- Product Subgroup:
- Lugs
- Product Color:
- Pink
- Product Material:
- Aluminum
Blackburn ATL2-14 – Frequently Asked Questions
1) What wire size does the Blackburn ATL2-14 lug take?
The ATL2-14 is sized for 2 AWG conductor. It's a compression lug, so the barrel is crimped onto the conductor rather than screwed down, and it is sized for one conductor size only. If your run is 1/0 or 4 AWG, you need the matching ATL part for that size, not this one.
2) Will the Blackburn ATL2-14 bolt to a 1/4 inch stud on my panel or bus bar?
Yes. The ATL2-14 has a single mounting hole sized for a 1/4 inch stud, so it lands on a 1/4-20 bolt or stud at a lug pad, bus bar, or breaker. Being a one-hole tongue, it resists rotation only through bolt torque, so if the pad has two holes and the conductor may be pulled on, a two-hole lug is the better choice.
3) Do I need a crimp tool for the Blackburn ATL2-14, or can I torque it down?
It's a compression lug, not a set-screw or mechanical lug, so it has to be crimped with a hydraulic or battery compression tool using the die that matches the pink 2 AWG code. There is no allen screw to tighten. If you want a tool-free termination, you need a mechanical set-screw lug instead of the ATL series.
4) Can I use an aluminum lug like the ATL2-14 on copper conductor?
The ATL2-14 barrel is aluminum. Aluminum-bodied compression lugs of this type are dual-rated AL/CU in many lines, but nothing in the ATL2-14 record states a copper rating, so treat it as the aluminum-conductor lug it is described as and use a copper compression lug for copper runs. The aluminum body is also why it's supplied for use with joint compound at the connection.
5) What does the pink color on the Blackburn ATL2-14 mean?
Pink is the die-color code on this lug, and it is the fastest way to confirm you have the right crimp die and the right conductor size before you squeeze it. Color code pink on the ATL series corresponds to the 2 AWG barrel, which matches the ATL2-14's 2 AWG rating. Match the pink die set in your compression tool to the pink band on the lug.
6) What is the exact part number and origin for the Blackburn 2 AWG one-hole compression lug?
Manufacturer part number ATL2-14, Blackburn brand, made in Mexico. Distributors ordering the family should note the numbering: the 2 in ATL2 is the 2 AWG conductor and the 14 is the 1/4 inch stud hole, so adjacent models change one or the other.
