20713 Viega ProPress tee Smart Connect technology Copper, 4'' x 4'' x 2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Country Of Origin:
- Made In Germany
- Material Type:
- Copper
- Product Dimension:
- 4'' x 4'' x 2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 4.681"
- Product Height:
- 6.453"
- Product Weight:
- 4.02 lbs
- Product Width:
- 7.913"
Viega 20713 – Frequently Asked Questions
1) What size branch does the Viega 20713 ProPress copper tee take?
The 20713 is a reducing tee: 4 inch on both run ends and 2 inch on the branch. Use it where a 4 inch copper main needs a 2 inch takeoff without stepping the whole line down. All three ends are press connections, not sweat or threaded.
2) Will a Viega ProPress 4 inch tee work on my existing copper line, or do I need to sweat it?
No torch needed. The 20713 is a copper press fitting that mates to standard copper tube at the 4 inch run and 2 inch branch. You cut, deburr, mark insertion depth and press with a tool and jaw or ring sized for that diameter. A 4 inch press takes a large-diameter ring and actuator, not a standard jaw set.
3) What does Smart Connect mean on a Viega ProPress tee?
Smart Connect is the feature that makes an unpressed joint leak during pressure testing, so a connection you missed shows itself on the test rather than after the walls are closed. On a 4 x 4 x 2 tee with three separate presses, that matters, since a large fitting in a tight ceiling is easy to leave one end short on.
4) What is the Viega part number for a 4 x 4 x 2 ProPress copper tee?
Part number 20713. That is the manufacturer number to quote for the copper ProPress reducing tee with 4 inch run ends and a 2 inch branch.
5) Is a 4 inch copper press tee heavy enough to need extra support?
It weighs 4.02 lbs bare, and a 4 inch copper main full of water adds far more. Support the run each side of the tee rather than letting the fitting carry pipe weight, and hang the 2 inch branch independently so it does not load the joint.
6) Is the Viega 20713 tee made in the USA?
It is made in Germany. Worth knowing up front if your project carries a domestic sourcing requirement, since a Buy American or similar clause will rule this fitting out regardless of how it performs.
