28870 Viega MegaPressG cap Smart Connect technology Carbon steel, 4"
Manufacturer Resources
Product Specs
- Connection Type:
- P
- Material Type:
- Carbon Steel
- Product Dimension:
- 4"
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 5.193"
- Product Height:
- 4.646"
- Product Weight:
- 2.746 lbs
- Product Width:
- 5.193"
- Product Material:
- Carbon steel
Viega 28870 – Frequently Asked Questions
1) What size pipe does the Viega 28870 MegaPressG cap fit?
The Viega MegaPressG 28870 is a 4 inch press fitting for carbon steel pipe. It presses onto the pipe end with a crimp tool rather than threading or welding, so the pipe end needs to be cut square and deburred, with the fitting fully seated before pressing.
2) Can I use a MegaPressG fitting on a gas line?
MegaPressG is Viega's gas-rated press system for black iron and carbon steel pipe, and the 28870 is the 4 inch carbon steel cap in that line. The standard MegaPress (non-G) sealing element is for water and other non-gas service, so the two lines are not interchangeable on a fuel gas system. Keep all fittings on a gas run in the MegaPressG family.
3) Will the Viega 28870 press cap work with copper or stainless pipe?
No. It's a carbon steel fitting sized for 4 inch carbon steel or black iron pipe. For copper you need Viega's copper press system (ProPress) and for stainless you need the stainless press line, both of which use different sealing elements and jaw profiles.
4) What does Smart Connect mean on a Viega MegaPressG cap?
Smart Connect is Viega's unpressed-connection feature: a fitting that has not been pressed will leak visibly during pressure testing instead of holding, so a missed joint shows up on test rather than after the wall is closed. On a large 4 inch run that is the practical check before you button up.
5) Is the Viega 28870 cap threaded or does it press on?
Press only. The connection type is press (P), so there is no thread and no pipe dope or tape involved. If the pipe end you are capping is already threaded, a press cap will still work as long as you cut back to clean, round, undamaged pipe of the right outside diameter and mark the insertion depth.
6) What is a press cap used for on a gas or steel piping job?
A cap closes off the open end of a pipe permanently, typically to terminate a stub-out, cap a future branch left for expansion, or dead-end a run during phasing. The 4 inch MegaPressG version does it without hot work, which is why it gets specified in occupied buildings where welding or torch work means a hot work permit and a fire watch.
7) Where is the Viega 28870 MegaPressG cap made?
Made in Germany. That matters on institutional and federal work where country of origin has to be documented on the submittal.
