2GANG DUPLEX RECEPT COVER
Manufacturer Resources
Spec Sheet
Product Specs
- Idea Granular Category Code Igcc:
- 4425 >> Electrical box covers
- Number Of Knockouts:
- 0
- Product Group:
- Boxes & Enclosures
- Product Type:
- Raised Device Cover
- Selling Unit Of Measure:
- each
- Standards:
- UL E28688
- Surface Finishing:
- Aluminum lacquer
- Department:
- Electrical
- Product Subgroup:
- Box Covers
- Product Color:
- Silver
- Product Material:
- Aluminum Die Cast
- Pack size (unit):
- 100
Thomas & Betts 2CCD – Frequently Asked Questions
1) What does the Thomas & Betts 2CCD cover actually fit?
The 2CCD is a two-gang box cover prepped for duplex receptacles, so it closes a 2-gang device box with two duplex receptacles behind it. It is a device cover, not a blank, and it has no knockouts, so there is no provision for running conduit or cable through the cover itself.
2) What should I use instead of the Thomas & Betts 2CCD if the box is a 3-gang switch box?
The 2CCD is a two-gang duplex receptacle cover in die cast aluminum with an aluminum lacquer finish. For a three-gang opening with toggle switches, the Steel City 3-GCS is a flat 3-gang switch box cover in pre-galvanized steel. Match the cover to both the gang count and the device type - a duplex receptacle cutout will not accept a toggle switch.
3) Is the 2CCD cover metal or plastic, and will it hold up outdoors or in a shop?
Die cast aluminum with an aluminum lacquer surface finish, silver in color. The lacquer gives it some corrosion resistance for garages, shops, and mechanical rooms. Aluminum die cast is the body material, so it is not a steel plate and not a wet-location gasketed cover on its own.
4) Does the Thomas & Betts 2CCD carry a UL listing for an inspected job?
Yes. The 2CCD cover is UL listed under file E28688, which is what an inspector or a spec writer on an institutional job will want to see on the submittal.
5) How many 2CCD covers come in a box, and can I buy just one?
The 2CCD is packed 100 to the box, with the selling unit of measure listed as each. For an MRO crib or a multi-family turn program that is a full case quantity, so plan on ordering in that volume rather than onesies.
6) I need covers for a mix of receptacle and switch boxes on one job - can I standardize on one part?
Not on a single part, because the cutouts differ. The 2CCD covers two-gang duplex receptacles and ships 100 per pack sold by the each, UL listed under E28688. For switch locations, the Steel City 3-GCS is the flat 3-gang switch cover, and the Mulberry 10093 is a flat gang box cover plate in the 1009 Series. Standardize on material and finish family rather than one SKU.
7) Is a galvanized steel gang box cover an equivalent substitute for the 2CCD aluminum cover?
They differ in material. The 2CCD is die cast aluminum with an aluminum lacquer surface finishing, silver in color. The Mulberry 10093 from the 1009 Series is a flat gang box cover plate in galvanized steel, as is the Steel City 3-GCS in pre-galvanized steel. Aluminum die cast is the usual choice where you want a non-ferrous cover; galvanized steel covers are the common pairing with steel boxes. Confirm gang count and device cutout before swapping either way.
8) What is the Thomas & Betts part number to order this 2-gang duplex cover?
Order it as Thomas & Betts 2CCD. That is the manufacturer part number for the two-gang duplex receptacle cover in die cast aluminum.
9) Does the 2CCD come with knockouts like some other gang box covers?
No. The 2CCD has zero knockouts - it is a solid die cast aluminum cover with the two duplex receptacle openings only. The comparable flat covers, the Mulberry 10093 1009 Series plate and the Steel City 3-GCS, are likewise flat cover plates rather than knockout-equipped enclosure covers. If your application needs a conduit entry through the cover, a flat receptacle cover is not the right part.
