Minerallac 3/8-16 x 1-9/16" Steel Drop-In Anchors with Setting Tool - Zinc Plated Professional Fastening System

Minerallac 3/8-16 x 1-9/16" Steel Drop-In Anchors with Setting Tool - Zinc Plated Professional Fastening System

(No reviews yet) Write a Review

Model: 60404J
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.64
$0.67
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Minerallac 3/8-16 x 1-9/16" Steel Drop-In Anchors with Setting Tool - Zinc Plated Professional Fastening System

Heavy-Duty Concrete Anchoring Solution with Professional Setting Tool

Minerallac delivers professional-grade concrete anchoring performance with these 3/8-16 x 1-9/16" steel drop-in anchors. Engineered with zinc plated steel construction and internal threading, these anchors provide reliable fastening strength for demanding applications. Each jar includes the professional setting tool for proper installation, ensuring consistent performance and secure attachment in concrete substrates.

Professional Features & Benefits

  • High Tension Strength: 2870 lbs capacity in 2000 psi concrete delivers secure holding power for critical applications
  • Superior Shear Performance: Up to 3160 lbs shear strength in 4000 psi concrete provides exceptional lateral load resistance
  • Zinc Plated Steel Construction: Corrosion-resistant finish extends service life in various environmental conditions
  • Internal Threading Design: 16 TPI internal threads ensure reliable bolt engagement and consistent clamping force
  • Complete Installation System: Includes professional setting tool for proper anchor deployment and optimal performance
  • Precise Embedment Specifications: 1.625" minimum embedment depth ensures proper concrete engagement and load transfer

Technical Specifications

  • Country Of Origin: China
  • Drill Size: 2-Jan
  • Minimum Embedment Depth: 1.625
  • Product Diameter: 8-Mar
  • Product Finish: Zinc Plated
  • Product Length: 1-9/16 in
  • Product Material: Steel
  • Product Type: Drop-In Achor
  • Shear Strength: 1138lbs in 2000psi normal weight concrete. 3160lbs in 4000psi normal weight concrete
  • Tension Strength: 2870 lbs in 2000 psi concrete
  • Thread Size: 16 TPI
  • Thread Type: Internal Threads
  • Ultimate Tension Strength: 538bs in 2000psi normal weight concrete. 2000bs in 4000psi normal weight concrete

Professional Applications

  • Structural Steel Connections
  • Heavy Equipment Mounting
  • Concrete Construction Projects
  • Industrial Facility Installations
  • Commercial Building Systems
  • Infrastructure Development
  • Professional Contractor Applications

Why Choose Minerallac Quality?

Minerallac steel drop-in anchors deliver proven reliability through precision engineering and zinc plated corrosion protection. The included professional setting tool ensures proper installation while the high-strength steel construction provides long-term durability in demanding concrete anchoring applications.

Manufacturer Resources

Product Specs

Country Of Origin:
China
Drill Size:
2-Jan
Minimum Embedment Depth:
1.625
Product Diameter:
8-Mar
Product Finish:
Zinc Plated
Product Length:
1-9/16 in
Product Material:
Steel
Product Type:
Drop-In Achor
Shear Strength:
1138lbs in 2000psi normal weight concrete. 3160lbs in 4000psi normal weight concrete
Tension Strength:
2870 lbs in 2000 psi concrete
Thread Size:
16 TPI
Thread Type:
Internal Threads
Ultimate Tension Strength:
538bs in 2000psi normal weight concrete. 2000bs in 4000psi normal weight concrete
Department:
Electrical

Minerallac 60404J – Frequently Asked Questions

1) What size bolt threads into the Minerallac 60404J drop-in anchor?
It takes a 3/8-16 bolt or threaded rod. The anchor body is internally threaded at 16 threads per inch, so the fastener threads down into the anchor rather than the anchor being a stud you thread a nut onto. That means you can remove and re-install the bolt, which is why drop-ins get used for hanging strut, trapeze supports, and equipment that may come back down later.
2) How deep does the hole need to be for a 3/8 inch steel drop-in anchor?
Minimum embedment is 1.625 inches, and the anchor itself is 1-9/16 inches long, so the anchor sits flush with the concrete surface and the hole must be drilled at least full anchor depth plus clearance for dust. Drop-ins are flush-set by design, which is what lets you fasten a base plate or channel tight against the slab with no protruding stud.
3) Do I need a separate setting tool for these drop-in anchors?
No. The jar of Minerallac 60404J anchors ships with the setting tool. A drop-in will not hold without being set: you drop it in the hole, drive the tool into the internal plug until the shoulder bottoms out, and that expands the anchor against the hole wall. Skipping the tool or under-driving it is the usual reason a drop-in spins or pulls.
4) Will a drop-in anchor work in block, brick, or the underside of hollow core plank?
No. This is a solid concrete anchor. The expansion plug needs a full depth of sound concrete around it to develop the 1.625 inch embedment, so hollow block, brick, and the voids in hollow core plank will not set it properly. For those substrates use a sleeve or screw anchor rated for hollow base material, or a toggle.
5) Can I use these zinc plated anchors outdoors or in a wet area?
The finish is zinc plating on steel, which is corrosion resistant for interior and protected conditions. For direct weather exposure, chemical exposure, coastal air, or anything submerged, a zinc plated carbon steel anchor is the wrong pick and you should be specifying a stainless drop-in instead.
6) Drop-in anchor or wedge anchor for hanging threaded rod from a slab?
Use the drop-in when you want a flush, removable connection: nothing sticks out of the slab until you thread rod into it, and the rod can be backed out later. A wedge anchor leaves a permanent stud projecting from the concrete and cannot be removed cleanly. For overhead trapeze and strut hangers on 3/8-16 rod, the drop-in is the normal choice; for a bolted base plate that never comes apart, a wedge anchor is simpler.
7) What is the Minerallac part number and how do these ship?
The part number is 60404J, a jar of 3/8-16 x 1-9/16 inch steel drop-in anchors with the setting tool included. Country of origin is China.
