3M Cable Tie 15 in Black Nylon 6/6 120 lbs Tensile Strength UL Listed Plenum Rated
Professional Cable Management with Curved Tip Design
The 3M Cable Tie delivers reliable wire bundling and harness component securing with its curved tip design for faster threading and installation. This 15 in black cable tie features Nylon 6/6 construction with 120 lbs tensile strength, UL Listed 62275 Type 21 or 21S certification, and plenum rating AH-2 for use in air handling spaces. Made in the USA with UV resistance and wide temperature range capability from -40�F to 185�F.
Professional Features & Benefits
- 120 lbs Tensile Strength: Provides secure bundling for demanding applications without slipping or failure under load
- 15 in Length with 4 in Maximum Bundle Diameter: Accommodates various wire bundle sizes from 0.1875 in to 4 in diameter
- UL Listed 62275 Type 21/21S & Plenum Rated AH-2: Certified for safe use in air handling spaces and commercial installations
- Nylon 6/6 Construction with UV Resistance: Ensures long-term durability in indoor and outdoor environments
- Curved Tip Design: Enables faster threading and installation, reducing labor time and effort
- Wide Operating Temperature Range -40�F to 185�F: Maintains performance across extreme temperature conditions
- 600V Maximum Voltage Rating: Suitable for electrical applications with proper insulation clearances
Technical Specifications
- Cable Length Imperial: 15 in
- Cable Length Metric: 381 mm
- Cable Tie Base Height: 15 in
- Cable Tie Length: 381 mm
- Color Family Incorporate Product Color: Black
- Flammability Rating: UL 94 V-2
- Manufacturer Catalog Number: 7000031860
- Manufacturing Origin: USA
- Maximum Bundle Diameter: 4 Inch
- Maximum Bundle Diameter Metric: 102 mm
- Maximum Insulation Outer Diameter Metric: 3.7 mm
- Maximum Insulation Outside Diameter: 0.145 in
- Maximum Operating Temperature: 85 Degree Celsius
- Maximum Operating Temperature Celsius: 85 Degree Celsius
- Maximum Operating Temperature Fahrenheit: 185 Degree Fahrenheit
- Maximum Recommended Voltage Rating: 600 V
- Minimum Bundle Diameter: 0.1875 Inch
- Minimum Bundle Diameter Metric: 4.8 mm
- Minimum Installation Temperature Celsius: -20 Degree Celsius
- Minimum Installation Temperature Fahrenheit: -4 Degree Fahrenheit
- Minimum Operating Temperature Celsius: -40 Degree Celsius
- Minimum Operating Temperature Fahrenheit: -40 Degree Fahrenheit
- Operating Temperature Celsius: 85 Degree Celsius
- Operating Temperature Fahrenheit: 185 Degree Fahrenheit
- Operating Temperature Range Celsius: -40 �C to 85 �C
- Operating Temperature Range Fahrenheit: -40 �F to 185 �F
- Overall Length Imperial: 15 in
- Overall Length Metric: 381 mm
- Overall Width Imperial: 0.298 in
- Overall Width Metric: 7.6 mm
- Package Height: 3.00000 in
- Package Length: 7.00000 in
- Package Weight: 0.9812 LBS
- Plenum Rated: Yes
- Product Material: Nylon 6/6
- Product Type: Standard
- Tape Type: Barricade
- Tensile Strength Imperial: 120 lbs
- Tensile Strength Metric: 54.43 kg
- Uv Resistant: Yes
Professional Applications
- Commercial HVAC Systems and Air Handling Units
- Electrical Panel and Control Cabinet Wiring
- Data Center Cable Management
- Industrial Equipment Wire Bundling
- Telecommunications Infrastructure
- Building Automation Systems
- Professional Electrical Installations
Why Choose 3M Quality?
3M Cable Ties deliver proven reliability with UL Listed certification, plenum rating for air handling spaces, and UV resistant Nylon 6/6 construction. Made in the USA with wide temperature range capability and 600V voltage rating, these cable ties provide the professional performance and safety standards required for demanding electrical and telecommunications applications.
Manufacturer Resources
Product Specs
- Cable Length Imperial:
- 15 in
- Cable Length Metric:
- 381 mm
- Cable Tie Base Height:
- 15 in
- Cable Tie Length:
- 381 mm
- Color Family Incorporate Product Color:
- Black
- Flammability Rating:
- UL 94 V-2
- Manufacturer Catalog Number:
- 7000031860
- Manufacturing Origin:
- USA
- Maximum Bundle Diameter:
- 4 Inch
- Maximum Bundle Diameter Metric:
- 102 mm
- Maximum Insulation Outer Diameter Metric:
- 3.7 mm
- Maximum Insulation Outside Diameter:
- 0.145 in
- Maximum Operating Temperature:
- 85 Degree Celsius
- Maximum Operating Temperature Celsius:
- 85 Degree Celsius
- Maximum Operating Temperature Fahrenheit:
- 185 Degree Fahrenheit
- Maximum Recommended Voltage Rating:
- 600 V
- Minimum Bundle Diameter:
- 0.1875 Inch
- Minimum Bundle Diameter Metric:
- 4.8 mm
- Minimum Installation Temperature Celsius:
- -20 Degree Celsius
- Minimum Installation Temperature Fahrenheit:
- -4 Degree Fahrenheit
- Minimum Operating Temperature Celsius:
- -40 Degree Celsius
- Minimum Operating Temperature Fahrenheit:
- -40 Degree Fahrenheit
- Operating Temperature Celsius:
- 85 Degree Celsius
- Operating Temperature Fahrenheit:
- 185 Degree Fahrenheit
- Operating Temperature Range Celsius:
- -40 °C to 85 °C
- Operating Temperature Range Fahrenheit:
- -40 °F to 185 °F
- Overall Length Imperial:
- 15 in
- Overall Length Metric:
- 381 mm
- Overall Width Imperial:
- 0.298 in
- Overall Width Metric:
- 7.6 mm
- Package Height:
- 3.00000 in
- Package Length:
- 7.00000 in
- Package Weight:
- 0.9812 LBS
- Plenum Rated:
- Yes
- Product Material:
- Nylon 6/6
- Product Type:
- Standard
- Tape Type:
- Barricade
- Tensile Strength Imperial:
- 120 lbs
- Tensile Strength Metric:
- 54.43 kg
- Uv Resistant:
- Yes
- Department:
- Electrical
- Product Subgroup:
- Cable Ties & Mounts
- Product Group:
- Cable Management & Identification
3M CT15BK120-C – Frequently Asked Questions
1) Can I use these cable ties in a return air plenum above a drop ceiling?
Yes. The 3M CT15BK120-C is plenum rated and carries a UL 94 V-2 flammability rating, so it is intended for air handling spaces such as ceiling return plenums. That rating is the reason inspectors accept a nylon tie in that space at all, so on a plenum job specify the plenum rated part rather than a standard bag of ties.
2) Will these hold up outdoors in sunlight and in unconditioned space?
The black Nylon 6/6 tie is UV resistant and rated for continuous service from -40 F to 185 F (-40 C to 85 C), so rooftop mechanical, attic, and exterior runs are within its range. One catch on cold work: minimum installation temperature is -4 F (-20 C). Nylon gets brittle below that, so a tie cinched in deep cold can crack even though its service rating goes lower.
3) Is 120 lb tensile strength enough for bundling heavy feeder cable in a panel?
120 lbs (54.43 kg) minimum loop tensile is the heavy duty end of standard nylon ties, and it is the figure to check against how much weight the bundle puts on each tie, not the total bundle weight. The tie body is 0.298 in (7.6 mm) wide, which spreads load over the jacket instead of cutting into it. For cable support inside a panel, ties bundle the conductors; they are not a substitute for the strut, clamps, or cable supports the installation actually hangs from.
4) What exact 3M part number and pack count am I ordering?
Order 3M part CT15BK120-C, manufacturer catalog number 7000031860, supplied 100 ties to the pack in black. It is made in the USA, which matters if your job carries a domestic sourcing requirement.
5) What is the voltage rating on these cable ties?
Maximum recommended voltage rating is 600 V. That covers normal building branch circuit and feeder work up to 600 V, and it means the tie is not a substitute for insulation, only a bundling device used with properly insulated conductors.
6) Do I need a special tool or tensioner to install these?
No tool is required. The curved tip threads the tie into the head by hand, which is what speeds up overhead and in-panel work where you are feeding the tail blind. A tension tool is optional and only worth it when you want repeatable tension and a flush cut-off across a large install.
7) Why choose black ties instead of natural nylon for exposed cable runs?
Black is the color to use anywhere the tie sees daylight. The black Nylon 6/6 formulation is UV resistant, and black also disappears against conduit and cable jackets on exposed work in data rooms and mechanical spaces.
