3M Temflex Cotton Friction Tape 1755 3/4 in x 60 ft Black Electrical Protection Tape
Professional Grade Cotton Fabric Electrical Tape for Wire and Cable Protection
3M Temflex Cotton Friction Tape 1755 delivers superior abrasion and cut-through protection for wire and cable splices in electrical maintenance applications. This professional-grade black cotton friction tape features a durable cotton fabric backing with rubber adhesive, providing reliable performance in both indoor and outdoor environments with temperature resistance from 15 to 176�F (-10 to 80�C).
Professional Features & Benefits
- Superior Protection: Cotton fabric backing provides exceptional abrasion and cut-through resistance for critical wire and cable splice protection
- Wide Temperature Range: Operates reliably from 15 to 176�F (-10 to 80�C) for versatile environmental applications
- High Tensile Strength: 48 lb/inch tensile strength ensures secure, long-lasting electrical connections and splices
- Rubber Adhesive System: Provides excellent adhesion and conformability for reliable electrical insulation
- Indoor/Outdoor Versatility: Suitable for both indoor and outdoor electrical maintenance applications
- Professional Dimensions: 3/4 in x 60 ft roll size optimized for electrical maintenance and repair work
- Extended Shelf Life: 5-year shelf life ensures long-term storage reliability for maintenance inventory
Technical Specifications
- Adhesive Type: Rubber
- Application: Electrical Maintenance
- Backing Material: Cotton Fabric
- Backing Thickness Imperial: 13 mil
- Backing Thickness Metric: 0.33 mm
- Color Family Incorporate Product Color: Black
- Indoor Outdoor: Both
- Manufacturer Catalog Number: 7000058870
- Maximum Operating Temperature: 80
- Maximum Operating Temperature Celsius: 80 Degree Celsius
- Maximum Operating Temperature Fahrenheit: 176 Degree Fahrenheit
- Overall Length Imperial: 60 ft
- Overall Length Metric: 18.3 m
- Overall Thickness Metric: 0.33 mm
- Overall Width Imperial: 0.75 in
- Overall Width Metric: 19 mm
- Package Height: 0.75000 in
- Package Length: 3.30000 in
- Product Material: Cotton Fabric
- Shelf Life: 5 Year
- Tensile Strength Imperial: 48 lb/inch
- Tensile Strength Metric: 840.5 N/100mm
Professional Applications
- Electrical Maintenance and Repair
- Wire and Cable Splice Protection
- Industrial Electrical Systems
- Commercial Building Maintenance
- Utility and Power Distribution
- Telecommunications Infrastructure
- HVAC Electrical Connections
Why Choose 3M Quality?
3M Temflex Cotton Friction Tape 1755 represents proven electrical protection technology with RoHS 2011/65/EU compliance and a 5-year shelf life. The cotton fabric construction and rubber adhesive system deliver the reliability and durability that electrical professionals trust for critical wire and cable protection applications.
Manufacturer Resources
Product Specs
- Adhesive Type:
- Rubber
- Backing Material:
- Cotton Fabric
- Backing Thickness Imperial:
- 13 mil
- Backing Thickness Metric:
- 0.33 mm
- Color Family Incorporate Product Color:
- Black
- Indoor Outdoor:
- Both
- Manufacturer Catalog Number:
- 7000058870
- Maximum Operating Temperature:
- 80
- Maximum Operating Temperature Celsius:
- 80 Degree Celsius
- Maximum Operating Temperature Fahrenheit:
- 176 Degree Fahrenheit
- Overall Length Imperial:
- 60 ft
- Overall Length Metric:
- 18.3 m
- Overall Thickness Metric:
- 0.33 mm
- Overall Width Imperial:
- 0.75 in
- Overall Width Metric:
- 19 mm
- Package Height:
- 0.75000 in
- Package Length:
- 3.30000 in
- Product Material:
- Cotton Fabric
- Shelf Life:
- 5 Year
- Tensile Strength Imperial:
- 48 lb/inch
- Tensile Strength Metric:
- 840.5 N/100mm
- Department:
- Electrical
- Product Type:
- Friction Tape
- Product Group:
- Cable Management & Identification
- Product Subgroup:
- Electrical Tape
- Application:
- Electrical Maintenance
3M 1755-3/4X60FT – Frequently Asked Questions
1) Is 3M 1755 friction tape the same thing as regular black vinyl electrical tape?
No, and swapping one for the other is a common mistake. The 1755 is a cotton fabric tape with rubber adhesive, sold for mechanical protection of splices. Vinyl tape (the Temflex and Scotch Super 33+ style rolls) is the stretchy plastic tape you use for insulating and jacketing. Vinyl conforms and seals; friction tape armors. Most maintenance carts carry both.
2) Can 3M Temflex 1755 friction tape be used outdoors and in unconditioned spaces?
Yes, the 1755 is rated for indoor and outdoor use, with an operating range up to 176 F (80 C). That covers rooftop equipment, attic and mechanical room runs, and exterior splices. It is a cotton fabric tape with rubber adhesive, so it is not a substitute for a properly sealed splice in standing water, it is the abrasion jacket over one.
3) What is the 3M part number for the black 3/4 inch x 60 ft Temflex friction tape?
Order it as 3M 1755-3/4X60FT. The manufacturer catalog number is 7000058870. It is the black cotton friction tape in the 3/4 inch by 60 foot roll, one size and one color in this line, so there is nothing else to specify on the order.
4) Can I use friction tape on a splice that runs hot, like a motor lead or a ballast connection?
The 1755 handles up to 176 F (80 C) continuous. Motor lead and lighting ballast compartments frequently sit above that, so check the actual conductor temperature rating before wrapping. If the splice runs hotter than 80 C, use a high temperature glass cloth or silicone rubber splicing product instead, the cotton and rubber construction here is not a high heat tape.
5) How long can I keep 3M Temflex 1755 friction tape on the shelf before it goes bad?
Shelf life on the 1755 is 5 years. That makes it reasonable to buy the 20 roll case for a facility stockroom or a fleet of service trucks rather than ordering singles per job. Store it out of heat, the rubber adhesive is the part that ages.
6) Is 3M Temflex 1755 friction tape RoHS compliant for a spec submittal?
The 1755 carries RoHS 2011/65/EU compliance, which is the line most institutional and government submittals are looking for on a consumable like this.
