You may also like
43560 Viega PureFlow Crimp tee PolyAlloy, 1'' x 1'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- Crimp1 x Crimp2 x Crimp3
- Country Of Origin:
- United States
- Material Type:
- Polyalloy
- Product Dimension:
- 1'' x 1'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 3"
- Product Height:
- 0.95"
- Product Weight:
- 0.05 lbs
- Product Width:
- 1.95"
- Product Material:
- PolyAlloy
Viega 43560 – Frequently Asked Questions
1) Is the Viega 43560 PureFlow tee a full 1 inch on all three outlets?
Yes. The Viega 43560 PureFlow tee is 1 inch by 1 inch by 1 inch, so the run and the branch are all the same size. If you need to step the branch down, you want a reducing tee instead, not this one.
2) What kind of connection does the Viega 43560 tee use, and do I need a special tool?
All three ports are crimp connections, so it installs with PEX crimp rings and a crimp tool, not a press tool or a clamp tool. Slide a ring over the tubing, seat the tubing fully on the fitting barb, then crimp. Crimp1 x Crimp2 x Crimp3 is how the three ports are called out.
3) Will the Viega 43560 crimp tee work with a press tool or stainless clamp rings?
No. This is a crimp fitting, built for copper crimp rings and a crimp tool. Viega press fittings and clamp style connections are different systems with different fitting geometry, so do not mix them on the same fitting. If your crew is tooled for press, order the press version of the 1 inch tee rather than this one.
4) Is the Viega 43560 a plastic or metal tee, and does that matter for aggressive water?
It is a PolyAlloy body, so there is no brass or copper in the waterway. That is the usual reason crews pick a polymer tee over brass on wells or water that is known to attack metal fittings. It also means the fitting weighs almost nothing at 0.05 lbs, which helps on long runs of unsupported manifolded tubing.
5) How much room do I need in the wall cavity for a 1 inch Viega PureFlow crimp tee?
The tee measures 3 inches long, 1.95 inches wide, and 0.95 inches high. Add the crimp ring and the length of the crimp tool jaws on each side when you lay it out in a 2x4 bay; the fitting itself clears a standard stud cavity easily, but the tool swing is what usually decides the location.
6) Is the Viega 43560 PureFlow tee made in the USA?
Yes, the 43560 PureFlow crimp tee is made in the USA. That matters on public and institutional jobs where domestic sourcing is a condition of the contract.
How fast can I get the Viega 43560 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Viega 43560 come with a warranty?
Absolutely. The Viega 43560 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Viega 43560?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
