49545 Viega PureFlow Press tee Smart Connect technology Polymer, 1'' x 3/4'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Country Of Origin:
- United States
- Material Type:
- Polymer
- Product Dimension:
- 1'' x 3/4'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 2.917"
- Product Height:
- 1.299"
- Product Weight:
- 0.104 lbs
- Product Width:
- 2.24"
- Product Material:
- Polymer
Viega 49545 – Frequently Asked Questions
1) What size tubing does the Viega 49545 PureFlow press tee connect?
The Viega 49545 is a reducing press tee sized 1 inch x 3/4 inch x 1 inch. The run is 1 inch on both ends and the branch takes 3/4 inch, so it is the fitting for pulling a 3/4 inch branch line off a 1 inch main.
2) Does the Viega 49545 press tee need to be pressed, or can it be crimped with a standard PEX ring tool?
It is a press fitting. The 49545 PureFlow tee is made for Viega's press system with Smart Connect technology, so it is installed with a press tool and jaw, not a copper crimp ring or cinch clamp tool. Smart Connect is the feature that lets an unpressed connection leak visibly during pressure test so you can find the miss before closing the wall.
3) Is the Viega 49545 tee metal or plastic?
Polymer. The 49545 PureFlow tee has a polymer body rather than brass or bronze, which keeps it out of the way of dezincification concerns on aggressive water and keeps the weight down at 0.104 lbs per fitting.
4) How much space do I need to fit a 1 inch x 3/4 inch x 1 inch Viega PureFlow tee in a stud bay?
The 49545 measures 2.917 inches long, 2.24 inches wide and 1.299 inches high. That footprint clears a standard 3-1/2 inch deep 2x4 bay easily, but leave extra room on each side for the press jaw to close around the sleeves.
5) What part number do I order for a Viega 1 x 3/4 x 1 PureFlow polymer press tee?
Viega part number 49545. It is a single configuration, no finish or handing options to specify, sold as the 1 inch x 3/4 inch x 1 inch polymer PureFlow press tee.
6) Is the Viega 49545 PureFlow tee made in the USA?
Yes, the 49545 is US-made, which matters on public and institutional jobs carrying domestic-content requirements on plumbing materials.
