4SQ RNG 1G, 7/8IN RSD, 5CU
Manufacturer Resources
Product Specs
- Country Of Origin:
- United States (US)
- Number Of Knockouts:
- 0
- Product Type:
- Electrical box extension
- Selling Unit Of Measure:
- each
- Standards:
- UL E2969
- Volume:
- 5 in³
- Department:
- Electrical
- Product Group:
- Electrical Enclosures
- Product Subgroup:
- Boxes
- Product Type2:
- Square Rings
- Product Size:
- 4 Inches Length x 4 Inches Width
- Product Color:
- Silver
- Product Material:
- Steel
Steel City 405-B – Frequently Asked Questions
1) What is the Steel City 405-B ring used for?
The 405-B is a single gang square ring (mud ring) that mounts to a 4 inch square steel box and reduces the opening to one device, such as a switch or receptacle. It raises the device 7/8 inch out from the box so the device sits flush with the finished wall surface, and it adds 5 cubic inches of volume to the box.
2) Will the 405-B ring fit a standard 4 inch square junction box?
Yes. The 405-B measures 4 inches by 4 inches and is made to sit on the face of a standard 4 inch square box, lining up with the box's two device ears. It is a one gang ring, so it covers the box and leaves a single device opening.
3) How much drywall thickness does the 7/8 inch raised ring cover?
The 405-B has a 7/8 inch rise, so it is the one to use where the wall finish in front of the box is close to 7/8 inch, for example double layer 1/2 inch drywall or drywall over furring. For a single layer of 1/2 inch board, a 1/2 inch rise ring is the closer match, and for a flush surface a flat ring.
4) Does the 405-B ring add to the box fill calculation?
It does. The ring carries 5 cubic inches of its own volume, which you add to the box volume when you run a box fill count for conductors, devices and clamps.
5) Is the 405-B ring UL listed, and what is it made of?
It carries UL file E2969. The ring is steel with a silver finish, which is what an inspector expects for a metal device ring bonded to a steel box.
