Metallics 6-32 x 4 in. Flat Head Phillips Machine Screws
Professional Steel Zinc Machine Screws for Electronics & Industrial Applications
Metallics delivers reliable fastening solutions with these 6-32 x 4 inch flat head Phillips machine screws featuring steel zinc construction. These professional-grade machine screws provide secure fastening for electrical, plumbing, heating and air conditioning applications with zinc yellow finish popular in electronics applications. Built to ASME B18.6.3-1998 dimensional standards with AISI 1006-1022 material specifications for consistent performance.
Professional Features & Benefits
- 6-32 Thread Size: Standard threading provides reliable engagement and holding power for diverse fastening applications.
- 4 Inch Length: Extended length accommodates thick materials and provides versatile installation options.
- Steel Zinc Material: Corrosion-resistant zinc finish extends service life while maintaining electrical conductivity for electronics applications.
- Flat Head Design: Countersunk profile sits flush with surfaces for clean, professional installations without protrusion.
- Phillips Drive: Standard #2 Phillips driver size ensures easy installation with common tools and reliable torque transfer.
- ASME B18.6.3-1998 Compliance: Manufactured to dimensional standards ensuring consistent fit and performance across applications.
- 550 lb Minimum Tensile Strength: High-strength construction provides reliable holding power for demanding applications.
Technical Specifications
- Arra Compliant: N
- Buy American Compliant: No
- Country Of Origin: MUL
- Department: Electrical
- Dimensional Standard: ASME B18.6.3-1998
- Division: Electrical H1
- Drive Type: Phillips
- Driver Size: #2
- Fastener Head Height: 0.069 - 0.083 in.
- Fastener Head Type: Flat
- Fastener Head Width: 0.238 - 0.262 in.
- Fastener Length: 4
- Field Application: Electrical, Plumbing, Heating and Air Conditioning Industries
- Gaging Diameter: 0.22
- Hardness: Rockwell B70-B100
- Height: 4.57 in
- Language Code: EN
- Material: Steel Zinc
- Material Standard: AISI 1006 - 1022
- Neurspe: https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Mach_Screw.pdf
- Order Minimum Imperial: 100
- Order Minimum Uom Imperial: JR
- Pack Type: Jar
- Phillips Recess Depth: 0.094
- Phillips Recess Diameter: 0.168
- Phillips Recess Width: 0.029
- Product Details: Machine Screw
- Product Family: Electrical Supplies
- Product Finish: Zinc
- Product Group: Fasteners
- Product Height: 116.078 MM
- Product Length: 3 in
- Product Subgroup: Screws
- Product Type: Machine Screw
- Product Weight: 467 g
- Product Width: 76.2 MM
- Protrusion Gaging Diameter: 0.021 - 0.036 Above
- Series: FM and FMP
- Sub Division: Electrical-E H2
- Tensile Strength: 550 lb minimum
- Thread Per Inch: 32
- Thread Standard: ANSI/ASME B1.1
- Thread Type: UNC
- Type2: Machine Screw
- Weight: 1.03 lbs
- Width: 3 in
Professional Applications
- Electronics Assembly and Repair
- Electrical Panel and Equipment Installation
- HVAC System Components
- Plumbing Fixture Mounting
- Industrial Equipment Assembly
- Commercial Building Maintenance
- Professional Service Applications
Why Choose Metallics Quality?
Metallics machine screws deliver consistent performance with steel zinc construction meeting AISI 1006-1022 material standards and ASME B18.6.3-1998 dimensional specifications. The zinc finish provides corrosion resistance while maintaining the electrical properties essential for electronics applications, backed by 550 lb minimum tensile strength for reliable fastening performance.
Manufacturer Resources
Product Specs
- Minimum Purchase:
- 100 units
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Dimensional Standard:
- ASME B18.6.3-1998
- Division:
- Electrical H1
- Drive Type:
- Phillips
- Driver Size:
- #2
- Fastener Head Height:
- 0.069 - 0.083 in.
- Fastener Head Type:
- Flat
- Fastener Head Width:
- 0.238 - 0.262 in.
- Fastener Length:
- 4
- Field Application:
- Electrical, Plumbing, Heating and Air Conditioning Industries
- Gaging Diameter:
- 0.22
- Hardness:
- Rockwell B70-B100
- Language Code:
- EN
- Material Standard:
- AISI 1006 - 1022
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Mach_Screw.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- JR
- Pack Type:
- Jar
- Phillips Recess Depth:
- 0.094
- Phillips Recess Diameter:
- 0.168
- Phillips Recess Width:
- 0.029
- Product Group:
- Fasteners
- Product Height:
- 4.57 in
- Product Length:
- 3 in
- Product Weight:
- 1.03 lbs
- Product Width:
- 3 in
- Protrusion Gaging Diameter:
- 0.021 - 0.036 Above
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 550 lb minimum
- Thread Per Inch:
- 32
- Thread Standard:
- ANSI/ASME B1.1
- Thread Type:
- UNC
- Department:
- Electrical
- Product Subgroup:
- Screws
- Product Type:
- Machine Screw
- Type2:
- Machine Screw
- Series:
- FM and FMP
- Product Finish:
- Zinc
- Product Details:
- Machine Screw
- Product Material:
- Steel Zinc
Metallics JFMP64 – Frequently Asked Questions
1) How many 6-32 x 4 in. Metallics flat head machine screws come in a jar, and is there an order minimum?
The JFMP64 flat head Phillips machine screws ship in a jar of 100, and 100 (one jar) is the order minimum. Jar weight is listed at 1.03 lbs.
2) Will a 6-32 x 4 in. machine screw thread into my existing 6-32 tapped hole or nut?
Yes. These are 6-32 UNC, 32 threads per inch, made to ANSI/ASME B1.1 thread standard, so they mate with any standard 6-32 tapped hole, nut, or threaded insert. Dimensions follow ASME B18.6.3-1998, so head and thread geometry match any other spec-conforming #6 flat head machine screw.
3) Do these Metallics machine screws meet Buy American or ARRA requirements for a public project?
No. The JFMP64 screws are listed as not Buy American compliant and not ARRA compliant, with multiple countries of origin. On a federally funded job with domestic sourcing requirements, you will need a domestically produced fastener instead.
4) What size driver do I need for Metallics 6-32 flat head Phillips machine screws?
A #2 Phillips bit. The recess is 0.168 in. diameter, 0.094 in. deep, with a 0.029 in. recess width, which is standard Phillips geometry for a #6 screw, so a worn or oversized bit will cam out before it seats the head.
5) How much load will a 6-32 steel zinc machine screw hold?
550 lb minimum tensile strength per screw, with the steel hardened to Rockwell B70-B100 and made from AISI 1006-1022 steel. That is a low-carbon, unhardened-grade fastener: fine for mounting equipment, panels, and fixtures, but not a substitute for a graded cap screw in a structural or high-vibration load path.
6) Is a zinc finish screw OK for outdoor or damp locations?
These are steel with a zinc finish, which gives corrosion resistance for indoor electrical, plumbing, and HVAC work. Zinc plating is a sacrificial coating, so for sustained wet exposure, washdown areas, or coastal sites, specify a stainless machine screw instead rather than relying on zinc.
7) What is the gaging diameter on these flat head screws and why does it matter for inspection?
Gaging diameter is 0.22 in., with protrusion gaging 0.021 to 0.036 in. above the gage. Those are the ASME B18.6.3 head-conformance checks an inspector or QA buyer uses to confirm the head profile is within spec before accepting a lot.
