6 AL TP COMP LUG 1HL No10BOLT GRY
Manufacturer Resources
Product Specs
- Country Of Origin:
- Mexico (MX)
- Product Group:
- Wire Termination
- Product Type:
- Aluminum One-Hole Lug
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Stud Size:
- #10
- Sub Brand Label:
- Blackburn
- Type2:
- Cable or wire lug
- Voltage Rating:
- 35 kV
- Department:
- Electrical
- Product Subgroup:
- Lugs
- Product Color:
- Grey
- Product Material:
- Aluminum
Blackburn ATL6-10 – Frequently Asked Questions
1) What wire size does the Blackburn ATL6-10 compression lug take?
The ATL6-10 is sized for 6 AWG conductor. It's a one-hole compression lug, so the barrel is crimped onto the conductor rather than screwed down, and the pad bolts to the bus or ground bar with a #10 bolt. Using it on a conductor other than 6 AWG will give you a crimp that won't hold.
2) Is the ATL6-10 lug rated for medium-voltage cable terminations?
It carries a 35 kV voltage rating, which puts it in medium-voltage territory for terminating shielded cable, concentric neutrals and grounding connections in pad-mount and switchgear work. It is UL listed under file E9809.
3) Do I need a crimp tool for the ATL6-10 or can I torque it down?
It's a compression lug, not a mechanical set-screw lug, so it has to be crimped with a die-type compression tool onto the 6 AWG conductor. There's no set screw to torque. If you don't have a crimper on site, a mechanical screw-type lug for 6 AWG is the alternative.
4) Why is the Blackburn ATL6-10 grey, and does the color mean anything?
Grey is the ATL6-10's body color. On compression lugs the color often identifies the die or conductor range for inspection after the crimp, so crews stocking several sizes can tell terminations apart on a tray at a glance. Match the die called out for the lug when you crimp it.
5) Is the ATL6-10 sold individually or in a bag?
Sold each. If you're terminating a three-phase run plus ground you'll want to count the lugs per conductor and order accordingly rather than expecting a multi-pack.
6) Where is the Blackburn ATL6-10 made?
Country of origin is Mexico. That's the detail procurement teams need for domestic-preference or Buy America documentation on public jobs, so confirm your project's sourcing requirement before specifying it.
