Metallics QK5M 8 x 1/2 in. 1/4...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.09
$0.09
Metallics QK5M 8 x 1/2 in. 1/4 Hex Head Slotted Sharp Point Self-Piercing & Tapping Screws - Steel Zinc - 1000qty

Metallics QK5M 8 x 1/2 in. 1/4 Hex Head Slotted Sharp Point Self-Piercing & Tapping Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: QK5M
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.09
$0.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
8 x 1/2 in. 1/4 Hex Head Slotted Sharp Point Self-Piercing & Tapping Screws - Steel Zinc - 1000qty

  • Additional Notes

    • Other sizes and quantities available by request.| Head dimensions of self-piercing screws differ firom those of standard tapping screws. | There is no single standard for self·piercing screw dimensions. These values are offered as a guide; deviations from these specifications may occur.

  • Features

    • Hex 1/4 Head with Slotted Drive
    • Undercut area beneath the head allows greater length of thread engagement.
    • 8 Diameter, 1/2" Length
    • Twin lead threads help to reduce driving torque.
    • Steel Zinc Material

Manufacturer Resources

Product Specs

Minimum Purchase:
1000 units
Arra Compliant:
N
Buy American Compliant:
No
Division:
Electrical H1
Drive Type:
Slotted
Driver Size:
#8
Fastener Head Height:
0.096 - 0.11 in.
Fastener Head Type:
Hex
Fastener Head Width:
0.244 - 0.25 in.
Fastener Length:
2-Jan
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell C28-38
Language Code:
EN
Material Standard:
AISI 1018 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Head_Slot_Sharp_Pt_Self_Pierce_TS.pdf
Order Minimum Imperial:
1000
Order Minimum Uom Imperial:
TH
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
4.57 in
Product Length:
3 in
Product Weight:
3.02 lbs
Product Width:
3 in
Screw Point Type:
Sharp Point
Slot Depth:
0.052 - 0.074
Slot Width:
0.045 - 0.054
Sub Division:
Electrical-E H2
Thread Per Inch:
15
Washer Od:
0.322 - 0.348 in.
Washer Thickness:
0.019 - 0.031 IN
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Self-Piercing & Tapping Screw
Type2:
Self-Piercing & Tapping Screw
Series:
JQK
Product Finish:
Zinc
Product Details:
Self-Piercing & Tapping Screw
Product Material:
Steel Zinc

Metallics QK5M – Frequently Asked Questions

1) Do I need to pre-drill a pilot hole for the Metallics QK5M self-piercing screws?
No. The QK5M is a sharp point self-piercing and tapping screw, so it pierces and forms its own thread in sheet metal without a pilot hole. Twin lead threads cut the driving torque, which matters when you are running hundreds of them into duct or enclosure sheet.
2) Will a #8 x 1/2 in. self-piercing screw hold in sheet metal duct and electrical boxes?
That is the intended use. Metallics lists the QK5M for electrical, plumbing, heating and air conditioning work, and the 1/2 inch length is sized for thin gauge material like duct, strut accessories, and panel or box sheet. The undercut beneath the head leaves more usable thread engaging the metal than a standard tapping screw of the same length.
3) Can I use these on a Buy American or ARRA-funded job?
No. The QK5M is listed as not Buy American compliant and not ARRA compliant, with country of origin reported as multiple. For a federally funded project with domestic sourcing requirements you will need a domestically produced fastener instead.
4) What driver do I need for the Metallics QK5M hex head screw?
The head is a 1/4 inch hex with a slotted drive, so you can run it with a 1/4 inch hex nutsetter or back it out with a flat blade. The slot measures 0.045 to 0.054 inch wide and 0.052 to 0.074 inch deep, and the head width is 0.244 to 0.25 inch. Driver size is listed as #8.
5) Is a self-piercing screw head the same size as a standard tapping screw head?
No, and it matters if you are matching existing fasteners. Metallics notes that self-piercing screw head dimensions differ from standard tapping screws, and that there is no single industry standard for self-piercing dimensions, so the published figures are a guide. On the QK5M, head height runs 0.096 to 0.11 inch across a 0.244 to 0.25 inch hex.
6) How hard is the Metallics QK5M screw, and what steel is it made from?
Case hardness is Rockwell C28-38 on AISI 1018 to 1022 steel with a zinc finish. That hardness is what lets the sharp point pierce sheet steel without snapping the shank, and the zinc plating gives basic indoor corrosion protection rather than exterior-grade coating.
7) What is the thread count on the Metallics QK5M, and does the washer-style head seal the hole?
Threads run 15 per inch. The head has an integral washer face with a 0.322 to 0.348 inch outside diameter and 0.019 to 0.031 inch thickness, which spreads bearing over the pierced hole. It is a bearing surface, not a gasket, so it does not weather-seal a penetration on its own.
