90460 Viega MegaPress flange Smart Connect technology 316 stainless steel, 2''
Manufacturer Resources
Product Specs
- Connection Type:
- P
- Material Type:
- 316 Stainless Steel
- Product Dimension:
- 2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Flanges
- Product Type:
- Flange
- Product Length:
- 6.142"
- Product Height:
- 3.606"
- Product Weight:
- 5.049 lbs
- Product Width:
- 6.142"
- Product Material:
- 316 stainless steel
Viega 90460 – Frequently Asked Questions
1) What size pipe does the Viega 90460 MegaPress fitting connect to?
The Viega 90460 is a 2 inch MegaPress fitting in 316 stainless steel. It presses onto 2 inch pipe, so your run has to be 2 inch at the point of connection; smaller lines need a different size in the MegaPress range.
2) Can I thread or solder the Viega 90460, or does it have to be pressed?
It is a press-connection fitting. There is no thread and no socket for solder on the press ends, so it is installed with a Viega-approved press tool and the matching 2 inch jaw. If your tie-in point is threaded, you need a transition fitting to get from thread to press.
3) Is the Viega 90460 MegaPress fitting stainless or carbon steel?
It is 316 stainless steel throughout. That is the grade you want where the line sees moisture, washdown, coastal air, or mildly corrosive service, rather than the carbon steel MegaPress bodies used on plain black pipe runs.
4) Does the Viega 90460 have Smart Connect, and what does that actually do for me on the job?
Yes, the 90460 is built with Viega's Smart Connect feature. In practice it is a leak path designed into the sealing element so an unpressed connection weeps during pressure test instead of passing inspection and failing later. It does not remove the need to press every joint, it just makes a missed one show up while you can still fix it.
5) How much room do I need around a 2 inch MegaPress 90460 fitting?
Plan on a body measuring 6.142 x 6.142 x 3.606 inches, and add clearance beyond that for the press tool jaw to seat square on the fitting. Tight ceiling cavities and close-wall runs are where 2 inch press fittings get awkward, so check the jaw swing before you commit the layout.
6) Where is the Viega 90460 MegaPress fitting made?
Made in Germany. That matters on public and institutional work where country of origin has to be documented in the submittal package.
