Viega 90655 MegaPress coupling...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$534.29
$484.29

Viega 90655 MegaPress coupling With stop Smart Connect technology 316 stainless steel, 4'' x 4''

(No reviews yet) Write a Review

Model: 90655
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$534.29
$484.29
Adding to cart… The item has been added
Free Shipping on orders over $199.99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
90655 Viega MegaPress coupling With stop Smart Connect technology 316 stainless steel, 4'' x 4''

Manufacturer Resources

Product Specs

Connection Type:
P1 x P2
Material Type:
316 Stainless Steel
Product Dimension:
4'' x 4''
Department:
Plumbing
Product Group:
Plumbing Fittings
Product Subgroup:
Couplings
Product Type:
Coupling
Product Length:
7.874"
Product Height:
5.185"
Product Weight:
4.13 lbs
Product Width:
5.185"
Product Material:
316 stainless steel

Viega 90655 – Frequently Asked Questions

1) What size pipe does the Viega MegaPress 90655 coupling join?
The Viega 90655 MegaPress coupling is a 4 inch by 4 inch fitting, so it joins two runs of 4 inch pipe press to press. Both ends are press connections (P1 x P2), no threading or welding at either end.
2) Is the Viega 90655 MegaPress coupling made of 316 stainless or carbon steel?
316 stainless steel. That is the corrosion resistant grade, which is what you want on wash-down areas, coastal or chemically aggressive environments, and process lines where a carbon steel MegaPress fitting would not hold up. The fitting is made in Germany.
3) Does the Viega 90655 coupling have a stop, and when would I want one without?
It is a coupling with stop. The internal stop centers the fitting so each pipe end bottoms out at a fixed insertion depth, which is what you want on a normal new joint. A coupling without stop is the one to use for repairs or tie-ins where you need to slide the fitting fully onto one pipe end and then back it over the joint, because you cannot spring 4 inch pipe apart.
4) What is Smart Connect on the Viega 90655 and why does it matter on a big 4 inch line?
Smart Connect is the unpressed-joint indicator built into the fitting. On a pressure test, a connection that was missed leaks visibly at low pressure so you find it before the system is charged. On a 4 inch stainless run with a limited number of large joints, that is the check that keeps you from chasing a missed press behind finished work.
5) How much does the Viega 90655 4 inch MegaPress coupling weigh and how big is it?
4.13 lbs, measuring 7.874 inches long with height and width both at 5.185 inches. Worth knowing before you plan the hanger spacing and the clearance around the joint, since a 4 inch press tool with the right jaw or ring needs room to swing around the fitting body.
6) What part number should I order for the Viega 4 inch MegaPress 316 stainless coupling with stop?
Order Viega part number 90655. That is the 4 inch by 4 inch MegaPress coupling with stop in 316 stainless steel.
