94762 Viega ProPress tee Smart Connect technology Copper, 1-1/4'' x 1'' x 3/4''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Material Type:
- Copper
- Product Dimension:
- 1-1/4'' x 1'' x 3/4''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 1.76"
- Product Height:
- 2.646"
- Product Weight:
- 0.516 lbs
- Product Width:
- 3.839"
- Product Material:
- Copper
Viega 94762 – Frequently Asked Questions
1) What pipe sizes does the Viega 94762 ProPress tee connect?
The Viega 94762 is a reducing press tee sized 1-1/4 inch x 1 inch x 3/4 inch. All three ends are press connections (P1 x P2 x P3), so the run goes 1-1/4 to 1 inch with a 3/4 inch press branch. There are no threaded or solder ends on it, so every joint gets pressed.
2) Does the Viega 94762 have Smart Connect, and what does that actually do for me on the job?
Yes, the 94762 tee is built with Viega's Smart Connect feature. It is a small deformation in the sealing element that lets an unpressed connection leak a little when the system is put under pressure, so you find the joint you missed during test instead of after the wall is closed. It does not change the press procedure itself.
3) Is the Viega 94762 press tee copper or bronze?
Copper. The 94762 ProPress tee is a copper body fitting, so it is intended for copper tube systems rather than carbon steel or stainless lines. It is made in Germany.
4) How much room do I need to fit this 1-1/4 x 1 x 3/4 press tee in a joist bay or wall cavity?
Plan around a fitting that measures 3.839 inches wide, 2.646 inches high and 1.76 inches long. Add clearance beyond that for the press jaw to swing around each of the three sockets, which is usually what controls the space rather than the fitting itself.
5) Do I need any solder, flux or extra parts to install the Viega 94762 tee?
No solder, flux or torch. The 94762 ships as the tee with its sealing elements in place; you cut and deburr the tube, mark insertion depth, and press each of the three joints with the correct jaw for that size. You do need a press tool with jaws covering 1-1/4 inch, 1 inch and 3/4 inch, since all three ports are press.
6) Which port on the 94762 is the branch?
The size order reads 1-1/4 x 1 x 3/4, so the 1-1/4 inch and 1 inch ends form the run and the 3/4 inch end is the branch. Use it where a 1-1/4 inch main steps down to 1 inch past the takeoff and you are dropping a 3/4 inch line to a fixture group or riser.
7) What is the Viega part number and weight for the 1-1/4 x 1 x 3/4 copper press tee?
Order it as Viega 94762. It weighs 0.516 lbs, which matters when you are pulling a count of them for a riser package or checking a freight line on a large order.
