95475 Viega MegaPress transition coupling Smart Connect technology 304 stainless steel, 1'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 (IPS) x P2 (CTS)
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Couplings
- Product Type:
- Tee
- Product Length:
- 3.398"
- Product Height:
- 1.78"
- Product Weight:
- 0.43 lbs
- Product Width:
- 1.78"
- Product Material:
- 304 stainless steel
Viega 95475 – Frequently Asked Questions
1) What does the Viega MegaPress 95475 transition coupling actually connect?
The 95475 is a 1 inch x 1 inch transition coupling that joins IPS (iron pipe size) on one end to CTS (copper tube size) on the other, so it ties a 1 inch black iron or steel pipe run into 1 inch copper tube. Both ends are press, not threaded or soldered. Body is 304 stainless steel.
2) Can I use the Viega 95475 to go from 1 inch steel pipe to 1 inch copper without threading or soldering?
That is exactly what it does. The IPS end presses onto 1 inch steel or black iron pipe and the CTS end presses onto 1 inch copper tube, so no pipe threading, no cutting oil, no torch on the copper side. You still need the correct MegaPress press tool jaw for the IPS end and a copper press jaw sized to the CTS end.
3) How much room do I need to fit the Viega 95475 between two pipe ends?
The coupling is 3.398 inches long overall and 1.78 inches across in both height and width. Allow for that 1.78 inch body diameter plus press tool jaw clearance around the fitting, which is usually the limiting factor in a tight joist bay or against a wall.
4) What is Smart Connect on the Viega 95475 and why does it matter on the job?
Smart Connect is the feature designed into the sealing element so an unpressed connection leaks visibly during pressure testing instead of passing inspection and failing later. On a 1 inch IPS-to-CTS transition buried in a mechanical room, that is how you catch a missed press before the walls close up.
5) Will a 304 stainless transition coupling cause a galvanic problem between my steel pipe and copper?
The body of the 95475 is 304 stainless steel, which is what Viega specifies for this MegaPress transition fitting rather than carbon steel. Material selection and any dielectric requirement for a steel-to-copper transition is a design call for your system and local code, but the fitting itself is stainless, not plain carbon steel.
