95800 Viega MegaPress coupling With stop Smart Connect technology 304 stainless steel, 1-1/4" x 1-1/4"
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1-1/4" x 1-1/4"
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Couplings
- Product Type:
- Coupling
- Product Length:
- 4.417"
- Product Height:
- 2.205"
- Product Weight:
- 0.849 lbs
- Product Width:
- 2.205"
- Product Material:
- 304 stainless steel
Viega 95800 – Frequently Asked Questions
1) What size pipe does the Viega MegaPress 95800 coupling join?
The Viega 95800 MegaPress coupling connects 1-1/4 inch to 1-1/4 inch, press on both ends (P1 x P2). It is a straight same-size coupling, so both ends take 1-1/4 inch pipe, not a reducer.
2) Does the Viega 95800 MegaPress coupling have a stop, and why does that matter on a repair?
It is a coupling with stop, meaning there is an internal shoulder that sets insertion depth on each end. That makes it quick to mark and set on new runs, but it will not slide over a cut pipe end the way a stopless (slip) coupling does. For a repair where you need to slide the fitting onto one side and back over the joint, order the stopless version instead.
3) Is the Viega 95800 coupling stainless or carbon steel, and what pipe is it for?
It is 304 stainless steel. That makes it the MegaPress S line for stainless pipe, not the carbon-steel MegaPress fittings used on black iron. Match the fitting metal to the pipe metal; running a stainless press fitting on a carbon system and vice versa is not an interchange.
4) What is Smart Connect on a Viega MegaPress fitting?
Smart Connect is Viega's unpressed-connection feature built into the 95800 coupling. During pressure testing an unpressed fitting leaks visibly so the installer can find and press it, rather than discovering a missed joint after the walls close up.
5) What is the part number and weight on the Viega 1-1/4 inch stainless MegaPress coupling with stop?
Manufacturer part number 95800, made in Germany, and it weighs 0.849 lbs each. Order by that number if you are standardizing a stainless press job across a building.
