American Standard Ultima Selec...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$563.51
$513.51
American Standard Ultima Selectronic Exposed Urinal Flush Valve, Diaphragm Type, Base Model, 0.5 gpf/1.9 Lpf - AMS-624B051

American Standard Ultima Selectronic Exposed Urinal Flush Valve, Diaphragm Type, Base Model, 0.5 gpf/1.9 Lpf - AMS-624B051

(No reviews yet) Write a Review

Model: 624B051.002
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$563.51
$513.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Ultima Selectronic Exposed Urinal Flush Valve, Diaphragm Type, Base Model, 0.5 gpf/1.9 Lpf

Manufacturer Resources

Product Specs

Product Type:
Flush Valve
Product Group:
Commercial
Product Subgroup:
Parts and Accessories
Family:
SELECTRONIC DIAPHRAGM FV
Luxury/Non Luxury:
Non Luxury
Residential Commercial:
Commercial
Product Length:
17.125
Product Height:
4.25
Product Weight:
6.506
Product Width:
10.375
Department:
Plumbing
Parts and Accessories Type:
Flush Valve
Application:
Toilet

American Standard 624B051.002 – Frequently Asked Questions

1) Is the American Standard 624B051 flush valve for a urinal or a water closet?
It's a urinal flush valve. The Ultima Selectronic exposed valve, model 624B051.002, flushes at 0.5 gpf (1.9 Lpf), which is a urinal flush rate, not a water closet rate. If you're fitting a toilet you need a 1.28 or 1.6 gpf closet valve instead.
2) Does the Ultima Selectronic urinal valve flush automatically, or does someone have to push it?
Sensor operated. Selectronic is American Standard's infrared automatic flush line, so the valve flushes hands-free when the user steps away. That's the reason it gets specified in schools, airports and healthcare restrooms where touch-free is the requirement.
3) Is the 624B051 an exposed valve or does it mount behind the wall?
Exposed. The valve body and sensor mount on the finished wall above the urinal, so there's no access panel or chase work involved. For a hidden installation you'd need a concealed Selectronic valve with a wall box instead.
4) Is this a diaphragm flush valve or a piston type?
Diaphragm. The 624B051 uses a diaphragm operating kit, which is the type most commercial maintenance shops stock rebuild kits for. If your building standardized on piston valves, the internal repair parts are not interchangeable.
5) How much space do I need for this exposed urinal flush valve, and how heavy is it?
Shipped dimensions are 17.125 by 10.375 by 4.25 inches and the valve weighs 6.506 lb. That weight is worth knowing on a retrofit: an exposed sensor valve is heavier than a manual handle valve, so make sure the supply nipple and wall support behind it are sound.
6) Will a 0.5 gpf urinal valve meet a low-flow water conservation spec?
0.5 gpf (1.9 Lpf) is the standard high-efficiency urinal flush rate and is the common target on water conservation retrofits. If your spec calls for a 0.125 gpf pint-flush urinal, this valve flushes too much water for that fixture.
7) What does the "base model" designation mean on this Ultima Selectronic valve?
Base model is the standard configuration, without the added options American Standard offers on higher trim levels of the Selectronic line. If a spec calls out a specific option package, confirm the full model number matches 624B051.002 before ordering.
8) Is this flush valve suitable for a high-traffic commercial restroom, or is it a residential product?
It's a commercial product. The Ultima Selectronic exposed valve is built for commercial restroom duty, which is what you want for office buildings, schools and public facilities rather than light residential use.
